304 316 Stainless Steel Fermentation Tanks / Industrial Storage Tank For Fruit Wine
304 316 Stainless Steel Fermentation Tanks / Industrial Storage Tank For Fruit Wine
304 316 Stainless Steel Fermentation Tanks / Industrial Storage Tank For Fruit Wine
304 316 Stainless Steel Fermentation Tanks / Industrial Storage Tank For Fruit Wine
304 316 Stainless Steel Fermentation Tanks / Industrial Storage Tank For Fruit Wine
304 316 Stainless Steel Fermentation Tanks / Industrial Storage Tank For Fruit Wine
Specifications
Model Number :
KQ Series
Certification :
ISO ,CE
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
500 Sets Per Month
Delivery Time :
25-30 days after get your advance payment
Packaging Details :
Standard Export Wooden Box
Name :
Fruit Wine Stainless Steel Fermentation Tank Mixing Tank
Material :
Sanitary Stainless Steel 304 / 316
Application :
Red Wine / Fruit Wine / Juice
Capacity :
100L-20000L
Function :
Steam Heating / Electricity Heating / No Heating
Speed of mixer :
18RPM ,36RPM ,48RPM ,72RPM ,3600 RPM
Make to order :
Yes
Origin :
Shanghai China
Description

304 316 Fruit Wine Stainless Steel Fermentation Tank Mixing Tank Storage Tank

1. Introduction of Stainless Steel Fermentation Tank .

Specifications:
Our equipment adopt 304 international standard stainless steel materials (mashed and lauter tanks can be luxury red copper material). You also can choice stainless steel polishes, carbon steel, spray finishing and so on.
The use of modern automatic plasma, laser cutting and welding of pure argon gas shield.PU heat preservation is adopted, and the external coating is made of fully welded stainless steel sheet.

The application of international standardized fermented beer production technology, a wide range of temperature control application technology, mirror polishing inside the tank, up to ≤0.8um≤0.6um≤0.2um polishing quality standards.

2. Technical Parameter :

Volume(L) Dimension Height(mm) Inlet &
Outlet(mm)
500 840 x 1000 2750 38
600 920 x 1000 2850 38
700 990 x 1000 2850 38
800 950 x 1220 3000 38
900 1010 x 1220 3000 38
1000 1060 x 1220 3150 51
1500 1160 x 1500 3350 51
2000 1340 x 1500 3410 51
3000 1410 x 2000 4000 51
4000 1620 x 2000 4250 51
5000 1810 x 2000 4300 51
6000 1980 x 2000 4550 51
7000 1930 x 2440 5000 51
8000 2060 x 2440 5000 51
9000 2180 x 2440 5050 51
10000 2300 x 2440 5050 51
12000 2270 x 3000 5600 51
15000 2530 x 3000 5700 51
20000 2640 x 3660 6400 51

304 316 Stainless Steel Fermentation Tanks / Industrial Storage Tank For Fruit Wine304 316 Stainless Steel Fermentation Tanks / Industrial Storage Tank For Fruit Wine
