Specifications
Model Number :
KQ-500L ,KQ -3000L
Certification :
CE ISO
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
100 Set Per Month
Delivery Time :
10 days after get your advance payment
Packaging Details :
Wooden Box
Name :
ice cream processing machine
Material :
Food Grade Stainless Steel 304
Certificate :
CE ,UL ,SGS
Flow :
500L/Hour - 1000L / Hour
After Service :
Yes
Warranty :
One year after reach your side .
Origin :
Shanghai China
Description

Stainless Steel Maturation Tank Ice Cream Production Line Aging Tank OEM

1. Maturation Tank :

Cold and hot tank is also known as aging tank, has the characteristics such as energy-saving, noise reduction, corrosion resistance, strong production capacity, easy cleaning. It is widely used in dairy industry, food, pharmaceutical, chemical, beverage and other industrial departments to heat, cool, insulate sterilization processing or store slurry. Especially suitable for the pasteurized milk, and is the necessary equipment in ice cream production line.

Specification(L) 10~50000
Design Pressure(Mpa) Atmospheric or under pressure
Material Carbon steel, stainless steel, enamel, graphite
Heating Forms Electrical heating with medium in jacket, external half-pipe coil steam heating, external half-pipe conduction oil heating, hot water infrared heating.
Cooling Forms Refrigeration medium in the internal pipe coil or jacket
Blending Power Model selection is made according to material viscosity, liquid-solid ratio, liquid specific gravity, solid specific gravity, solid granularity, rotation speed, paddle type, with or without baffle or internal coil.
Stirring Blade Forms Anchor type, frame type, flat paddle type, pitched paddle type, ribbon type, turbo type, pusher type and multiple compound type.
Seal Mechanical seal or stuff packing seal
Inner Surface Treatment polished or no polished
Discharge Valve Flanged ball valve open downward discharge valve and others
Technological Pipe Hole Manhole, sight glass, distillation hole, feed material hole, pressure gauge hole, temp. hole, etc. According to the process requirements increase or decrease

2. Technical Parameter :

Volume 300L 400L 500L 600L 800L 1000L 1500L 2000L 3000L
Body diameter(mm) Φ800 Φ800 Φ900 Φ1000 Φ1000 Φ1000 Φ1200 Φ1300 Φ1600
Body height(mm) 600 800 800 800 1000 1220 1220 1500 1500
Motor power(kw) 0.55 0.55 0.55 0.55 0.55 0.75 1.5 2.2 3
Stirring speed(rpm) 36r/min
Working pressure ≤0.09Mpa
Working temperature <100°C
Accessories Follow your request
