Optical Automatic Color Sorting Machine VGS AI Sorter High Capacity
Optical Automatic Color Sorting Machine VGS AI Sorter High Capacity
Specifications
Brand Name :
PHOENIX
Model Number :
VGS AI Optical Sorter
Place of Origin :
Hefei
MOQ :
1
Price :
Price Negotiable
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Delivery Time :
5-8 work days
Model :
VGS1
Chute :
1
Air Nozzle :
60
Air Pressure (MPa) :
0.6~0.8
Air Consumption (L/min) :
<1000
Power (kW) :
0.8
Description
VGS AI Optical Sorter AI Powered Sorting By Superior Detection To Superficial Or Internal Defects And FMs By Color, Size, Shape And Texture
Technical Features
Tailored Sorting Solution for Agricultural Seeds
  • High-capacity vibratory feeder evenly distributes pulses and beans into a single layer to minimize overlapping
  • Sealed scanning and control boxes provide machine with high-level dust protection
  • Field-proven Dust Control System integrated maintains high operation reliability and performance consistency, and minimizes downtime
  • Modular design of vertical frame size from 1 to 12 chutes (1/4/6/8/10/12) provides processors more flexibility
AI Powered 4-in-1 Multispectral Inspection System
  • Proprietary AI Deep Learning algorithms continuously improve defect recognition based on new samples
  • High-Resolution RGB Camera System
  • High-Intensity LED Illumination System
  • Optional NIR Camera System or SWIR Camera System
  • Market-leading precise detection to a wide range of defects of agricultural seeds by color, size, shape and texture features:
    • Discolored Seeds
    • Moldy Seeds
    • Broken/Cracked/Misshapen Seeds
    • Insect-damaged Seeds
    • Diseased Seeds: Fusarium-infected seeds
    • Foreign Materials: Stones, soil clumps, husks, wild weeds, mixed varieties
    • Chemical-coated/Dyed Seeds
    • Mutant/Hybrid Seeds
  • Customizable settings for diverse agricultural seeds
High-Performance Ejector System
  • Engineered for enhanced durability, optimized speed and air consumption
  • Accurate rejection and reliable performance at high-capacity sorting
  • Significant reduction in false rejection rate and total cost of ownership
  • 15-inch Industrial Touchscreen Control Panel
    • Intuitive HMI with multilingual support
    • Instant switching between product profiles
    • Comprehensive remote support system
      • Remote Access and Monitoring
      • Real-time Performance Dashboard
      • Live Expert Diagnosis
      • Interactive Troubleshooting
Optical Automatic Color Sorting Machine VGS AI Sorter High Capacity
Model Chute Air Nozzle Air Pressure (MPa) Air Consumption (L/min) Power (kW) Voltage Dimension (LWH)(mm) Weight* (kg)
VGS1 1 60 0.6~0.8 <1000 0.8 220V ~ 50/60Hz 1504×147×544 135
VGS4 4 256 0.6~0.8 <2000 2.9 220V ~ 50/60Hz 2170×2199×2076 1150
VGS6 6 384 0.6~0.8 <3000 4.4 220V ~ 50/60Hz 2800×2199×2076 1480
VGS8 8 512 0.6~0.8 <4000 5.9 220V ~ 50/60Hz 3430×2199×2076 1840
VGS10 10 640 0.6~0.8 <5000 7.3 220V ~ 50/60Hz 4070×2199×2076 2180
VGS12 12 768 0.6~0.8 <6000 8.8 220V ~ 50/60Hz 4835×2199×2076 2550
