VPM SWIR Polymer Sorter Infrared Sorting Machine High Capacity
VPM SWIR Polymer Sorter Infrared Sorting Machine High Capacity
Specifications
Brand Name :
PHOENIX
Model Number :
VPM SWIR Sorter
Place of Origin :
Hefei
MOQ :
1
Price :
Price Negotiable
Payment Terms :
,L/C,D/A,D/P,T/T,Western Union,MoneyGram
Delivery Time :
5-8 work days
Model :
VPM1
Chute :
1
Air Nozzle :
64
Throughput (t/h) :
0.2-0.8
Air Pressure (MPa) :
0.6-0.8
Air Consumption (m³/min) :
<0.5
Description
VPM SWIR Sorter Premium Polymer Detection To ABS, PS, PC, PP, PE Plastics In Shredded E-waste By Molecular Bond Vibrations
Technical Features
Tailored Sorting Solution for Plastic Recovery in E-waste
  • Innovative high-capacity 2-layer vibratory feeder evenly distributes shredded E-waste into a single layer to minimize overlapping
  • Sealed scanning and control boxes provide machine with high-level dust protection
  • Field-proven Dust Control System integrated maintains high operation reliability and performance consistency, and minimizes downtime
  • Modular design of vertical frame size from 4 to 8 chutes (4/6/8) provides processors more flexibility
Premium Industrial Inspection System
  • Dual-Band InGaAs-SWIR Camera System
  • Accurate detection to polymer types (ABS/PS/PC/PP/PE, etc.) based on molecular bond vibrations
  • Stable Air Cooling System maintains InGaAs sensor and Halogen Lighting System stabilities in hot environments
High-Performance Ejector System
  • Engineered for enhanced durability, optimized speed and air consumption
  • Accurate rejection and reliable performance at high-capacity sorting
  • Adjustable settings for typical plastic flake sizes (3-15 mm)
15-inch Industrial Touchscreen Control Panel
  • Intuitive HMI with multilingual support
  • Instant switching between product profiles
  • Comprehensive remote support system
  • Remote Access and Monitoring
  • Real-time Performance Dashboard
  • Live Expert Diagnosis
  • Interactive Troubleshooting

VPM SWIR Polymer Sorter Infrared Sorting Machine High Capacity

Specifications
Model Chute Air Nozzle Throughput (t/h) Air Pressure (MPa) Air Consumption (m³/min) Power (kW) Unpacked Weight (kg) Dimension (mm)
VPM1 1 64 0.2-0.8 0.6-0.8 <0.5 1.3 660 1135*1928*2385
VPM4 4 256 0.8-3.0 0.6-0.8 <2.0 4.2 1250 2150*1928*2385
VPM6 6 384 1.0-4.0 0.6-0.8 <3.0 6.2 1850 2825*1928*2385
VPM8 8 512 2.0-6.0 0.6-0.8 <4.0 8.2 2300 3518*1928*2385
