3D NIR Plastic Color Sorter Machine VPC Series Optical Color Sorter
3D NIR Plastic Color Sorter Machine VPC Series Optical Color Sorter
Specifications
Brand Name :
PHOENIX
Model Number :
VPC Optical Sorter
Place of Origin :
Hefei
MOQ :
1
Price :
Price Negotiable
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Delivery Time :
5-8 work days
Dimension (mm） :
1255×1670×1995
Power (kW) :
0.9
Model :
VPC1
Air Nozzle :
64
Description

VPC NIR Sorting Machine For ABS & PS Separation

VPC Series plastic sorting machine can detect same-in-color polymer contaminants. It can automatically recognize and remove non-PET impurities, and has the advantages of high sorting accuracy, high efficiency, easy operation and maintenance, compact structure, beautiful appearance and so on.

Product Description

ABS and PS plastics share very similar appearance and texture, making fast and accurate separation difficult with manual or conventional mechanical methods.

The VPC , equipped with advanced 3D NIR (near-infrared) sensor technology, is optimized for ABS/PS flake sorting. It precisely detects subtle material differences, and high-speed jet valves then separate the plastics with exceptional accuracy, achieving up to 99.9% purity in the final product.

3D NIR Plastic Color Sorter Machine VPC Series Optical Color Sorter

Specifications
Model Chute Air Nozzle Throughput (t/h) Air Pressure (MPa) Air Consumption (m³/min) Power (kW) Unpacked Weight (kg) Dimension (mm)
VPC1 1 64 0.4-0.8 0.6-0.8 <1.0 0.9 680 1255×1670×1995
VPC4 4 256 1.5-3.0 0.6-0.8 <2.0 2.9 1160 2170×1823×2007
VPC6 6 384 2.0-4.0 0.6-0.8 <3.0 4.4 1390 2438×1823×2007
VPC8 8 512 3.0-6.0 0.6-0.8 <4.0 5.9 1750 3064×1823×2007
VPC10 10 640 4.0-8.0 0.6-0.8 <5.0 7.3 2138 3734×1823×2007
