600mm Belt Infrared Sorting Machine 220V Colour Sorter Machine
600mm Belt Infrared Sorting Machine 220V Colour Sorter Machine
Specifications
Brand Name :
PHOENIX
Model Number :
HDF-R AI-RGB Sorter
Place of Origin :
Hefei
MOQ :
1
Price :
Price Negotiable
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Delivery Time :
5-8 work days
Model :
HDF2-R
Belt Width (mm) :
600
Air Pressure (MPa) :
0.6~0.8
Power (kW) :
6.6
Description
HDF2-R Deep Learning-Powered Sorting Machine

The HDF2-R series integrates deep learning and multi-dimensional UHDR technology to deliver highly precise material sorting with the industry's largest open-source model database. It efficiently handles sorting challenges in food processing, including chili peppers, peanuts, beans, and nuts, overcoming micro color and shape differences that conventional systems struggle to identify.

Product Description

The HDF2-R series products adopt deep learning and multi-dimensional UHDR technology, allowing users to share the industry's largest, most comprehensive, and most precise open-source model database. They have multi-dimensional and multi-characteristic identification of materials including color, shape, texture, area, light and shade, etc. Problems such as micro color difference, micro shape difference, and impurities of the same color that are hard to identify in conventional sorting can be easily solved.

Core Technologies
  • Four dimensional ultra definition recognition technology, strong integration of ultra clear and ultra precision, achieving extraordinary quality.
  • 20 billion level self-collected open source material database, which can be shared among users.
  • Optional high-end infrared configuration, better separation of foreign objects and impurities, easily achieving ultimate quality.
  • New optimized architecture design, stronger adaptability to harsh sorting conditions, allowing users to enjoy a superior sorting experience.
  • Higher throughput and better sorting effects endow product quality with stronger competitiveness, making it a great choice for high-end users.

600mm Belt Infrared Sorting Machine 220V Colour Sorter Machine

Specifications
Model Belt Width (mm) Air Nozzle Air Pressure (MPa) Air Consumption (m³/min) Voltage Power (kW) Dimension (mm) Unpacked Weight (kg)
HDF2-R 600 256 0.6~0.8 <2.1 220V~ 50/60Hz 6.6 4686×1924×2685 1589
HDF4-R 1200 512 0.6~0.8 <4.1 220V~ 50/60Hz 8.3 5087×2524×2685 2165
HDF6-R 1800 768 0.6~0.8 <4.1 220V~ 50/60Hz 11.8 4998×2963×2685 2419
