6x4 Construction Dump Truck European AVL Developed Diesel Engine BOSCH
6x4 Construction Dump Truck European AVL Developed Diesel Engine BOSCH
Specifications
Brand Name :
SINOWAY
Model Number :
SWTT50064WFL
Certification :
ISO9001
Place of Origin :
China
MOQ :
1 unit
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
50 units per month
Delivery Time :
30 days
Packaging Details :
Nude
Product name :
Truck Tractor
Engine :
European AVL developed heavy duty diesel engine, BOSCH common rail SCR
Rated power :
368kW(500Hp)/1900rpm
Max. torque :
2400N.m/1000~1400rpm
The fifth wheel :
JOST3.5"
GCW (Gross combination weight) :
100000Kg
Description

500HP Powerful Tractor Truck 6x4 Heavy Duty Tractor European AVL Developed Diesel Engine, BOSCH Common Rail SCR

Engine 　
European AVL developed heavy duty diesel
engine, BOSCH common rail SCR		 　
Type Six cylinder,four-stroke,water-cooled,
in-line,dry-liner,direct-injection,turbo charged
Controller type Electronic
Air cleaner Dry paper element
Rated power 368kW(500Hp)/1900rpm
Max. torque 2400N.m/1000-1400rpm
Bore×stroke 127*155mm
Displacement 12.54L
Main Technical Specification 　
Kerb weight 10000Kg
GCW (Gross combination weight) 100000Kg
Max.traveling speed 100km/h
Min. turning radius 8318mm
Grade ability 30%
Min.ground clearance 290mm
Approach angle 19°
Departure angle 45°
Fuel tank capacity 800L(350L+450L)
The fifth wheel JOST3.5"
Fuel consumption (empty loading) ＜30L/100km
Fuel consumption (full loading) ＜50L/100km
Dimensions 　
Overall size(L×W×H) 6890×2450×3870mm
Wheel base 3300+1350mm
Tread(F/R) 2065/1860mm
Overhang(F/R) 1550/840mm
Axle And Tyre 　
Front axle capacity 10000kg
Front axle type Drum
Rear axle capacity 2 16000kg
Rear axle type Drum
Ratio 4.769
Tyre size 12.00R20
Steering System 　
Steering device ZF
Driving position Left hand drive
Type Hydraulic assistance
Transmission System 　
Type FULLER tech mechanical transmission
with synchronizer
12 forward & 2 reverse
Ratio 　
Forward 1 12.1
Forward 2 9.52
Forward 3 7.31
Forward 4 5.71
Forward 5 4.46
Forward 6 3.48
Forward 7 2.71
Forward 8 2.13
Forward 9 1.64
Forward 10 1.28
Forward 11 1
Forward 12 0.78
Reverse 1 11.57
Reverse 2 2.59
Clutch And Brake 　
Clutch EATON
ABS WABCO
Service brake Foot operated compressed air
braking system,two circuits,front/rear distribution
Parking brake Hand operated
spring brake system,
brake force applies on the rear axle
Auxiliary brake JACOB engine brake
Emergency brake Two circuits,
front/rear distribution
Electric System 　
Batteries 24 Volt/165Ah
System voltage 24V
Suspension 　
Front suspension Tapered leaf spring 4
semi-elliptic leaf spring
Rear suspension Tapered leaf spring 9+6
semi-elliptic leaf spring

6x4 Construction Dump Truck European AVL Developed Diesel Engine BOSCH
