HITACHI Hydraulic Steering System 386HP Horsepower German Tech Diesel Engine
HITACHI Hydraulic Steering System 386HP Horsepower German Tech Diesel Engine
HITACHI Hydraulic Steering System 386HP Horsepower German Tech Diesel Engine
HITACHI Hydraulic Steering System 386HP Horsepower German Tech Diesel Engine
Specifications
Brand Name :
SINOWAY
Model Number :
SWDT38584A
Certification :
ISO9001
Place of Origin :
China
MOQ :
1 unit
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
50 units per month
Delivery Time :
30 days
Packaging Details :
Nude
Product name :
Dump Truck Tipper
Engine Type :
Mechanical, 6 cylinder,water-cooled turbocharged,direct-injection
Rated power :
284kw/1900rpm
Max. Torque :
1750N.m/1100~1450rpm
Transmission System :
German tech manual transmission Mechanical 9 speed, with synchronizer
Steering System :
Hydraulic steering with power assistance(HITACHI)
Description

386HP Horsepower German Tech Diesel Engine Construction Dump Truck HITACHI Hydraulic Steering System

Engine 　
Make German tech diesel engine
Type Mechanical, 6 cylinder,water-cooled turbocharged,direct-injection
Rated power 284kw/1900rpm
Max. Torque 1750N.m/1100~1450rpm
Main Technical Specification 　
Curb weight 16500Kg
Max. payload capacity 30000Kg
Rated axle loading capacity (Front) 2×7500kg
Rated axle loading capacity (Rear) 2×16000kg
Max. traveling speed 72km/h
Max. grade ability 30%
Tread 2065/1860/1860mm
Min. ground clearance 285mm
Fuel consumption 35L/100km
Fuel tank capacity 380L
Dimensions 　
Overall size(L×W×H) 9800×2500×3560mm
Wheel base 1850+3370+1350mm
Front overhang 1512mm
Rear overhang 1400mm
Transmission System 　
German tech manual transmission, Mechanical, 9 speed, with synchronizer 　
Ratio 　
Forward 14.05, 8.38, 6.22, 4.57, 3.40, 2.46, 1.83, 1.34, 1.00
Reverse 14.05
Dump Body 　
Overall length 7000mm
Overall width 2300mm
Overall height 1500mm
Side plate thickness 8mm
Under floor thickness 12mm
Hoist Front lifting
Steering System 　
Hydraulic steering with power assistance(HITACHI)
Driving position Left / Right hand drive
Axle And Tyre 　
Front axle Reinforced
Rear axle Reinforced
Rear axle ratio 5.921
Tyre size 12.00R20
Electric System 　
Batteries 2*12 Volt – 150 AH*2
Alternator 24 Volt/70A
Starter 24 Volt/7.80kw
Clutch And Brake 　
Single-plate dry coil-spring clutch, hydraulically operated with air assistance 　
Service brake Dual circuit compressed air brake
Parking brake Spring energy operating on rear wheels
Auxiliary brake Engine exhaust brake
Suspension 　
Front suspension 9 semi-elliptic leaf spring
Rear suspension 12 semi-elliptic leaf spring

HITACHI Hydraulic Steering System 386HP Horsepower German Tech Diesel Engine

HITACHI Hydraulic Steering System 386HP Horsepower German Tech Diesel Engine
