Specifications
Brand Name :
SUNBOW
Model Number :
SB-WRSFM
Certification :
UL E360625
Place of Origin :
Shenzhen, China
MOQ :
100 pcs each size each color
Price :
USD0.07-13.4 per PCS
Payment Terms :
L/C, T/T, Western Union, Paypal
Supply Ability :
100000000000000PCS per month
Delivery Time :
5~10 days upon order quantity
Packaging Details :
standard carton packing
Product name :
Black Polyolefin Heat Shrink End Cap Cable Accessories
Color :
default color black
Size :
11mm - 250mm
ul :
E360625
Material :
polyolefin and glue inside
Shrink Ratio :
2:1
Shrink Temp :
110~130 C
Operating Temp :
-45~+105 C
Cable Size :
6~240mm
Description

Black Polyolefin Heat Shrink End Cap Cable Accessories

The End Cap is adhesive lined to bond with the heat shrink it overlaps
Hot melt adhesive seals and insulates in one step to speed installation
Adhesive lining will prevent moisture penetration, allowing for long term storage of cable
Forms pressure-tight seal on ends of communication and power cables
Shrink ratio of 2:1 insulates a wide range of diameters and irregular shapes
Cross-linked UV resistant material improves chemical and temperature resistance
Continuous use temperature of up to 105 °C
Shrink temperature of 110-130 °C
Dual wall end cap, with internal wall of hot-melt adhesive provides excellent bonding to plastic and metals.
Capable of sealing the entire surface of a cable or wire

Specification

Property Test Method Standard Value
Operating temperature IEC 216 -45ºC to+105ºC
Tensile strength ASTM-D 2671 ≥13MPa
Elongation at break ASTM-D 2671 ≥300%
Tensile strength after aging ASTM-D-2671/120ºC,168hrs ≥10MPa
Elongation at break after aging ASTM-D-2671/120ºC,168hrs ≥240%
Dielectric strength IEC 243 ≥15kV/mm
Volume resistance ASTM-D-2303 ≥1×1013Ω.cm
Dielectric constant IEC 250 3.0
Radial shrinkage - ≥50%
Eccentricity ASTM-D-2671 ≤35%
Low Temperature Flexibility ASTM-D-2671 -40ºC, 4hrs, no cracking
Minimum shrink temperature - 90ºC

Minimum fully recovered

temperature

 - 130ºC

Dimension

Size

Size after recovery(mm)

Size as supplied (mm)

Cable sizes(mm)

Size

Inner Diameter

Wall thickness

Inner Diameter

Wall thickness

length

Outer Diameter

Φ 11

≤6.5

1.1±0.1

≥11

0.7±0.2

≥22

Φ6-9

Φ 16

≤8.0

2.5±0.1

≥16

1.2±0.2

≥70

Φ9-14

Φ 20

≤8.0

2.5±0.1

≥20

1.2±0.2

≥70

Φ9-17

Φ 25

≤11

2.5±0.1

≥25

1.2±0.2

≥80

Φ12-22

Φ 32

≤17

2.6±0.1

≥32

1.5±0.2

≥90

Φ17-27

Φ 40

≤15

2.8±0.1

≥40

1.5±0.2

≥90

Φ20-35

Φ 55

≤25

2.8±0.1

≥55

1.5±0.2

≥125

Φ28-45

Φ 75

≤30

3.2±0.1

≥75

1.8±0.2

≥145

Φ40-65

Φ 100

≤42

3.5±0.1

≥100

1.8±0.2

≥140

Φ50-90

Φ 120

≤59

3.5±0.1

≥120

1.8±0.2

≥155

Φ70-110

Φ 140

≤63

4.0±0.1

≥140

2.0±0.2

≥180

Φ90-130

Φ 250

≤94

4.0±0.1

≥250

2.0±0.2

≥270

Φ120-240
