• Product Name: Inverted Biological Research Grade Microscope
  Product model: MSS-M-OJC011
  1. Simple operation, powerful functions, flexible matching, and high cost-effectiveness.
  2. The bright field phase contrast model adopts high brightness halogen lighting (LED lighting can be selected) to ensure uniform brightness and excellent imaging quality throughout the entire field of view.
• 3.4K/1080P HD Resolution: Capture detailed images with high clarity.
• 4.Manual Focus Control: Precise manual adjustment for optimal viewing.
• 5.Biological Microscope Design: Ideal for detailed biological specimen observation.
• 6.Long Working Distance: Provides ample space for sample placement and observation.
• 7.LED Illumination: Ensures consistent lighting for clear and uniform visibility.

Optical System NIS Infinite Optical System
Eyepiece ·SW10X/22 ·SW10X/25 ·EW12.5X/17.5·WF15X/16 ·WF20X/12
Viewing Head Seidentopf Trinocular Head(build-in bertrand lens),inclined at 45°, Interpupilary Distance 47-78mm
Objective ·N-iPLFN PH Plan S-APO Phase Contrast Objective 4X 10X 20 X40X. 60X ·N-iPLFN Plan S-APO Objective 4X, 10X, 20 X 40X, 60X N-PLAPO Plan APO Obiective10X 20 X 40X 60X 100X
Nosepiece Encoded Sextuple Nosepiece with DIC Prism Slot
Sextuple Nosepiece with DIC Prism Slot
Electric Sextuple Nosepiece with DIC Prism Slot
Electric Sextuple Nosepiece with DIC Prism Slot
Condenser Long Working Distance Turret Condenser.NA0.55, WD=26mm. with 6 Modules for Phase Contrast. DiC and Brightfield
Long work distance electric Turret condenser,NA 0.55, WD=26mm.with 6 Modules for Phase Contrast, DIC and Brightfield
Long work distance electric Turret condenser,NA 0.55, WD=26mm,with 7 Modules for Phase Contrast, DIC and Brightfield
Transmission lighting Kohler illumination 12V100Whalogen lamp Kohler illumination 5WLED Kohler illumination 5W LED Kohler Illumination, 10W LED
Epi-illumination 100W mercury lamp · LED fluorescent lighting LED fluorescent lighting
Focusing System Coaxial Coarse and Fine Adjustment Electric coaxial coarse inching lifting mechanism
Stage The moving range is 130×100mm, the maximum speed is 50mm/s. and the resolution is 0.1um. Small worktables with different sizes can be installed on the top stage as required.
The moving range is 115×75mm, the maximum speed is 71mm/s, and the resolution is 0.1um. Small worktables with different sizes can be installed on the top stage as required.
3 Layers Mechanical Stage, Moving Range 130x85mm.
Flexible Knob, available for Different Size Small Stage.
Auxillary Stage Terasaki plate, φ38mm,φ54mm plate, General support plate, 96-hole plate tray
Intermediate magnification Multiplier 1X, 1.5x Multiplier 1X, 1.5x, CF file Multiplier 1X, 1.5x
Display Microscope use status display screen Touch screen, touch and display microscope status
Observation Method Bright field, Phase contrast, DiC, Fluorescence, Hoffman phase contrast
Filter Turntable Epi-fluorescent filter turntable Encoded Epifluorescent turntable Electric Epi-fluorescent
filter tumtable With high-performance filter Can be equipped with up to six Epifluorescent filters, Use one position during bright field Fluorescent Illuminator center align reflected light field of view stop of aperture stop

Shanghai Mengshengsheng International Trade Co., Ltd. specializes in optical products, including industrial microscopes and illumination systems. Established in 2018, the company offers a one-year warranty and rigorous quality control testing. It provides customized solutions and supports external displays, with delivery via DHL, UPS, and other logistics options.上海梦盛盛国际贸易有限公司专业从事光学产品,包括工业显微镜和照明系统.公司成立于2018年,提供一年保修和严格的质量控制测试.它提供定制的解决方案,并支持外部显示,通过DHL, UPS和其他物流选项交付.

Company overview 公司概述

Certificate 证书

Trade show participation 参加贸易展览会

Competitive advantages 竞争优势

Packaging & shipping specifications

包装和运输规格
