Specifications
Calibration :
Factory Calibrated
Display Type :
LCD Screen Display
customized support :
ODM, OEM
warranty :
1 Year
Logo/graphic design :
no
Focusing Distance :
25 mm
Model Number :
MSS-A-XUY-TD21191
External Display Support :
Yes
Place of Origin :
Shanghai, China
dimension :
Custom Sizes
illumination :
LED
Dioptric Adjustment :
other
IP Rating :
IP20
Brand Name :
MSS
MOQ :
1
Focus Type :
Auto Focus
Price :
$3,550-3,750
type :
Desktop flash tester
camera resolution :
Other
Description
Product descriptions from the supplier

Simple and easy to use, achieving one click fast and accurate measurement;

Automatic positioning of measurement objects, matching templates, measurement evaluation, and report generation;

Suitable for flat and rotating workpieces, meeting the measurement requirements of different specifications and types of products;

Combining dual telecentric lenses, high-resolution industrial cameras, and high-precision image analysis and processing algorithms;

Small products such as gears, hardware products, terminals, screws, electronic products, stamping products, plastic products, automotive parts, medical equipment, etc

Productparameters
Device Type Vertical flash tester
host dedicated machine
Display Size 21.5-inch, 1080P
Industrial Camera 20 million pixel USB 3.0
Industrial lens 0.108x dual telecentric lens
Lighting System Far center parallel light source (green)
Auxiliary light source 170 ring light (white)
measuring range 100*80mm
measurement accuracy 3um+L/100um
Display units 0.1um
software system Flash Tester Special Software
Input power supply AC220V,2A
Equipment size 215*440*635mm
Productspecifications
Eguipmentmodel confiauration
SC100-80 20millionUSBblackandwhite +0.109timestelecentrio +lowliaht+positiveliaht
Optional size
Loadglass 120*120*8mm
Calibrationboard 120*120*3mm
