Supplier Integrated Video Microscope Dual Lighting Independent Control 44-169mm Working Distance for Lab QC CE MSS-M-M2C
Supplier Integrated Video Microscope Dual Lighting Independent Control 44-169mm Working Distance for Lab QC CE MSS-M-M2C
Supplier Integrated Video Microscope Dual Lighting Independent Control 44-169mm Working Distance for Lab QC CE MSS-M-M2C
Supplier Integrated Video Microscope Dual Lighting Independent Control 44-169mm Working Distance for Lab QC CE MSS-M-M2C
Supplier Integrated Video Microscope Dual Lighting Independent Control 44-169mm Working Distance for Lab QC CE MSS-M-M2C
Supplier Integrated Video Microscope Dual Lighting Independent Control 44-169mm Working Distance for Lab QC CE MSS-M-M2C
Supplier Integrated Video Microscope Dual Lighting Independent Control 44-169mm Working Distance for Lab QC CE MSS-M-M2C
Supplier Integrated Video Microscope Dual Lighting Independent Control 44-169mm Working Distance for Lab QC CE MSS-M-M2C
Supplier Integrated Video Microscope Dual Lighting Independent Control 44-169mm Working Distance for Lab QC CE MSS-M-M2C
Supplier Integrated Video Microscope Dual Lighting Independent Control 44-169mm Working Distance for Lab QC CE MSS-M-M2C
Supplier Integrated Video Microscope Dual Lighting Independent Control 44-169mm Working Distance for Lab QC CE MSS-M-M2C
Supplier Integrated Video Microscope Dual Lighting Independent Control 44-169mm Working Distance for Lab QC CE MSS-M-M2C
Specifications
Place of Origin :
Shanghai, China
Calibration :
Factory Calibrated
Display Type :
LCD Display
Logo/graphic design :
no
Brand Name :
MSS
MOQ :
1
Focusing Distance :
The magnification is based on the objective lens
customized support :
ODM, OEM
warranty :
1 Year
Model Number :
MSS-M-M2C
External Display Support :
Yes
dimension :
Custom Sizes
illumination :
Transmitted & Reflected LED Lighting
Dioptric Adjustment :
other
IP Rating :
IP20
Price :
$550-590
Focus Type :
Manual Focus
type :
Digital Microscope
camera resolution :
1920*1080
Description
Product descriptions from the supplier

Built in multifunctional image processing software.

Two types of light sources are independently controlled and can be freely combined and adjusted.

The display angle can be adjusted from 45 ° forward to 120 ° backward.

The rear focusing mode extends the working distance, which supports 44-169mm.

Supplier Integrated Video Microscope Dual Lighting Independent Control 44-169mm Working Distance for Lab QC CE MSS-M-M2C
Physical Pixel 2.0MP
Sensor model SONY CMOS IMX291sensor
Highest resolution 1920 x 1080 (2,073,600pixel)
Sensor size 1/2.8" (6.058mm(H) × 4.415mm(V))
pixel size 2.9μm x 2.9μm
dynamic range 128dB
spectral response 380~650nm
exposure Real time automatic, single time automatic, manual adjustment Real time automatic, single time automatic and manual RG B adjustment
white balance respectively
FHD output resolution 1920X1080P60 maximum (adaptive according to the optional display)
Record format Photograph Resolution: 1920x1080 Format: JPG VideotapeResolution:maximum1920X1080P30,1280x720P60 Format:MOV
Record Path TF card (up to 128G, hot plug)
power supply DC 12V 3A
Working distance 44mm~169mm
Comprehensive magnification 8.9X~49.4X
Observation range 7mmx4mm~39mmx22mm

15.6"Screen parameters
Number of pixels 1920(horizontal) x 1080(vertical)
Pixel arrangement RGB Vertical Bar
Number of colors displayed 16.7M(8Bit)
surface treatment Anti-Glare
surface hardness 3H
Scope of view Horizontal 85°, vertical 85°
contrast ratio 800
brightness 500cd/(5-point average )
