1.5A 4 Pin RJ45 Connectors With Durability IP20 Class Contact Resistance ≤5mΩ
1.5A 4 Pin RJ45 Connectors With Durability IP20 Class Contact Resistance ≤5mΩ
1.5A 4 Pin RJ45 Connectors With Durability IP20 Class Contact Resistance ≤5mΩ
1.5A 4 Pin RJ45 Connectors With Durability IP20 Class Contact Resistance ≤5mΩ
Specifications
Brand Name :
KRONZ
Model Number :
RJ45S-10/E10K
Place of Origin :
Guangdong, China
Certification :
CE
MOQ :
80
Price :
Negotiable
Packaging Details :
Polybag packing
Delivery Time :
5-8 working days
Payment Terms :
T/T,Western Union,MoneyGram
Supply Ability :
100000 pieces per month
Pin :
4
Material of grip body :
TPU,black
Contact nut material :
Brass,nickel-plated
Seal material :
FPM/FKM
Ambient temperature :
-25~+85℃
Insulation resistance :
≥100MΩ
Voltage :
48V
Rated current :
1.5A
Description

The Connector RJ45 is made with high-quality materials to ensure durability and longevity. The contact carrier material is PA, black, which provides excellent resistance to wear and tear, as well as protection against corrosion. This material is also known for its high heat resistance, which ensures that the connector can operate at high temperatures without degrading or failing.


1.5A 4 Pin RJ45 Connectors With Durability IP20 Class Contact Resistance ≤5mΩ

Technical Data

Thread type RJ45
Contact nut material Brass, nickle-plated
Contact surface material Brass, gold-plated
Contact carrier material PA, black
Housing material TPU, black
Seal material FPM/FKM
Insulation resistance ≥100MΩ
Contact resistance ≤5mΩ
Pollution degree 3
Ambient temperature -25~+85℃
Mating cycles >100
Degree of protection IP20


Pin assignment Wire color PIN Rated current Voltage Wire gauge Cable outlet Length Model No.
1.5A 4 Pin RJ45 Connectors With Durability IP20 Class Contact Resistance ≤5mΩ 1 = YE
2 = OR
3 = WH
6 = BU		 4PIN 1.5A 48V 2×2×0.25,shielded
(2×2×24AWG)
Blueish green,
PVC,
OD=6.5		 Straight 10M RJ45S-10/E10K


Application


The KRONZ RJ45 connector can be used in a variety of product application occasions and scenarios. It can be used in the production of networking equipment, such as network switches, network routers, and network modems. The RJ45 connector can also be used in the production of Ethernet cables. The connector can be used in both commercial and residential applications, such as in the production of network cables for homes, offices, and data centers.


1.5A 4 Pin RJ45 Connectors With Durability IP20 Class Contact Resistance ≤5mΩ


1.5A 4 Pin RJ45 Connectors With Durability IP20 Class Contact Resistance ≤5mΩ
