48V RJ45 Ethernet Connector Modular Plug Shielded Cat6 Connectors Customized
48V RJ45 Ethernet Connector Modular Plug Shielded Cat6 Connectors Customized
48V RJ45 Ethernet Connector Modular Plug Shielded Cat6 Connectors Customized
48V RJ45 Ethernet Connector Modular Plug Shielded Cat6 Connectors Customized
Specifications
Brand Name :
KRONZ
Model Number :
RJ45S-5/E60K
Place of Origin :
Guangdong, China
Certification :
CE
MOQ :
80
Price :
Negotiable
Packaging Details :
Polybag packing
Delivery Time :
5-8 working days
Payment Terms :
T/T,Western Union,MoneyGram
Supply Ability :
100000 pieces per month
Contact carrier material :
PA,black
Contact nut material :
Brass,nickel-plated
Seal material :
FPM/FKM
Contact suface material :
Brass,gold-plated
Material of grip body :
TPU,black
Pin :
4, 8
Voltage :
48V
Length :
Customized
Description

Our RJ45 connectors are made with durable and high-quality materials to ensure long-lasting performance. The contact surface material used is brass, which is gold-plated to prevent corrosion and oxidation, providing a stable and reliable connection. The connector is also designed to prevent dust and water from entering, making it ideal for outdoor and harsh environments.

Our RJ45 connectors are available in 24AWG and 26AWG wire gauges, providing flexibility in selecting the perfect connector for your specific networking requirements. The thread type is RJ45, which is a standard interface for Ethernet connections.

48V RJ45 Ethernet Connector Modular Plug Shielded Cat6 Connectors Customized

Technical Data

Thread type RJ45
Contact nut material Brass, nickle-plated
Contact surface material Brass, gold-plated
Contact carrier material PA, black
Housing material TPU, black
Seal material FPM/FKM
Insulation resistance ≥100MΩ
Contact resistance ≤5mΩ
Pollution degree 3
Ambient temperature -25~+85℃
Mating cycles >100
Degree of protection IP20


Pin assignment Wire color PIN Rated current Voltage Wire gauge Cable outlet Length Model No.
48V RJ45 Ethernet Connector Modular Plug Shielded Cat6 Connectors Customized

1 = WH/OR
2 = OR
3 = WH/GN

4 = BU

5 = WH/BU
6 = GN

7 = WH/BN

8 = BN

 8 1.5A 48V 4×2×0.16,shielded
(4×2×26AWG)
Blueish green,
PVC,
OD=6.6		 Straight 5M RJ45S-5/E60K

Applications

One of the primary applications of this product is in the installation and maintenance of network cables. The RJ45 connector is designed to connect Ethernet cables to devices such as routers, switches, and servers. It is compatible with Cat6 RJ45 connectors, which support high-speed data transfer rates of up to 10 Gbps. This makes it ideal for use in data centers, offices, and other network-intensive environments.

48V RJ45 Ethernet Connector Modular Plug Shielded Cat6 Connectors Customized

48V RJ45 Ethernet Connector Modular Plug Shielded Cat6 Connectors Customized
