High Precision Longitudinal Welding Seamer 500mm length Seam Welding Machine
High Precision Longitudinal Welding Seamer 500mm length Seam Welding Machine
High Precision Longitudinal Welding Seamer 500mm length Seam Welding Machine
High Precision Longitudinal Welding Seamer 500mm length Seam Welding Machine
High Precision Longitudinal Welding Seamer 500mm length Seam Welding Machine
High Precision Longitudinal Welding Seamer 500mm length Seam Welding Machine
High Precision Longitudinal Welding Seamer 500mm length Seam Welding Machine
High Precision Longitudinal Welding Seamer 500mm length Seam Welding Machine
High Precision Longitudinal Welding Seamer 500mm length Seam Welding Machine
High Precision Longitudinal Welding Seamer 500mm length Seam Welding Machine
High Precision Longitudinal Welding Seamer 500mm length Seam Welding Machine
High Precision Longitudinal Welding Seamer 500mm length Seam Welding Machine
High Precision Longitudinal Welding Seamer 500mm length Seam Welding Machine
High Precision Longitudinal Welding Seamer 500mm length Seam Welding Machine
High Precision Longitudinal Welding Seamer 500mm length Seam Welding Machine
High Precision Longitudinal Welding Seamer 500mm length Seam Welding Machine
High Precision Longitudinal Welding Seamer 500mm length Seam Welding Machine
High Precision Longitudinal Welding Seamer 500mm length Seam Welding Machine
High Precision Longitudinal Welding Seamer 500mm length Seam Welding Machine
High Precision Longitudinal Welding Seamer 500mm length Seam Welding Machine
Specifications
Model Number :
XioFiTec/Hanyan
Brand Name :
XioFiTec/Hanyan
Place of Origin :
CHINA
Price :
100
Weight :
Customizable
Power Source :
Electric
Welding Current :
Adjustable
power source :
50Hz AC 200V /AC 380V
Name :
Longitudinal seam welding machine
Packaging Details :
Wooden Box
Description

Longitudinal seam welding machine/welding seamer/seam welder/seamer system

ZF-500

ZF500

Control power source

Single-phase of 50Hz AC 200V

welding power source

Three-phase of 50Hz AC 380V

Weld workpiece thickness

0.5～3.0mm

Welding workpiece diameter

800≥φ≥80mm

Effective length of the welding workpiece

≤500mm

Drag board moving speed range

100～1800mm/min

Pneumatic lift stroke of welding torch

100mm

The welding torch manually fine-adjusts the distance

Y to 30mm ± and Z to 30mm ±

Maximum allowable welding current of the host machine

500A

Mandrel diameter (mm)

70

Maximum welded workpiece (mm)

φ800

Weldable minimum workpiece (mm)

φ80

Weldable length (mm)

500

Weld workpiece thickness

0.5～ 3 mm

speed of welding

0.1~1.8 m / min (standard)

0.1~1.2 m / min (Optional)
