10G SFP+ AOC Active Optical Cables
10G SFP+ AOC Active Optical Cables
10G SFP+ AOC Active Optical Cables
10G SFP+ AOC Active Optical Cables
Specifications
Brand Name :
Seacent
Model Number :
10G SFP+
Certification :
ISO9001,ROHS
Place of Origin :
Shenzhen,China
MOQ :
1 piece
Payment Terms :
L/C,T/T,D/P
Supply Ability :
100,000 pieces per month
Delivery Time :
5-8 work days
Total Speed :
10G
Breakout Type :
1:1
Side A Speed :
10G NRZ
Side B Speed :
10G NRZ
Length :
1m-100m
Product name :
10G SFP+ AOC
Description

Applications:10G SFP+ AOC Active Optical Cables

Seacent Photonics' SFP+ 10G Active Optical Cables are direct-attach fiber solutions with integrated SFP+ connectors, specifically designed for high-density, cost-effective interconnections within racks and across adjacent racks. This single-channel, pluggable optical module offers an extremely convenient connectivity solution for 10 Gigabit Ethernet and Infiniband EDR applications. The module operates at a nominal wavelength of 850nm over multimode fiber systems, and its electrical interface utilizes a standard 20-contact edge-type connector, ensuring reliable performance and broad compatibility.


Product Features:

  • Electrical Interface Compliant with SFF-8431

  • 850nm VCSEL Laser and PIN Photo-Detector

  • Maximum Link Length: 150m over OM2 MMF / 300m over OM3 MMF

  • Hot-Pluggable

  • Integrated Digital Diagnostic Monitoring (DDM) Functions

  • Operating Case Temperature: 0°C to +70°C

  • RoHS Compliant


​Applications:​

  • 10G Ethernet

  • Data Centers

  • Infiniband transmission

Absolute Maximum Ratings:

Parameter Symbol Min. Max. Unit
Power Supply Voltage VCC -0.5 +3.6 V
Storage Temperature Tc -40 +85 ℃
Relative Humidity RH 0 85 %

Recommended Operating Conditions

Parameter Symbol Min. Typical Max. Unit
Supply Voltage VCC 3.13 3.3 3.45 V
Operating Case Temp. (Standard) Tca 0 — +70 ℃
Operating Case Temp. (Extended) Tca -40 — +85 ℃
Data Rate DR — — 10.3125 Gbps
Fiber Bend Radius Rb 3 — — cm
