200G QSFP56 AOC Active Optical Cables Multi-Mode
200G QSFP56 AOC Active Optical Cables Multi-Mode
200G QSFP56 AOC Active Optical Cables Multi-Mode
200G QSFP56 AOC Active Optical Cables Multi-Mode
200G QSFP56 AOC Active Optical Cables Multi-Mode
200G QSFP56 AOC Active Optical Cables Multi-Mode
Specifications
Brand Name :
Seacent
Model Number :
200G QSFP56
Certification :
ISO9001,ROHS
Place of Origin :
Shenzhen,China
MOQ :
1 piece
Payment Terms :
L/C,T/T,D/P
Supply Ability :
100,000 pieces per month
Delivery Time :
5-8 work days
Product name :
200G QSFP56 AOC
Total Speed :
200G
Breakout Type :
1: 1
Length :
1m-100m
Description

200G QSFP56 AOC Active Optical Cables Multi-Mode

This 200G QSFP56 Active Optical Cable (AOC) represents the cutting edge of high-speed data center interconnect technology, delivering ultra-high bandwidth of 200Gbps per lane. Utilizing advanced modulation technology and high-quality optical components, it offers exceptional transmission performance while maintaining excellent power efficiency and signal integrity. Fully compliant with industry standards and featuring plug-and-play, hot-swappable functionality with robust compatibility, it is the ideal short-reach interconnect solution for building next-generation 200/400G Ethernet, AI clusters, and high-speed storage networks.

Product Features:

  • Hot-pluggable QSFP56 form factor cable

  • Four-channel full-duplex, 53Gbps per lane

  • 4 channels 850nm VCSEL array

  • 4 channels PIN photo detector array

  • Power consumption <5.5W per end

  • Built-in digital diagnostic monitoring (DDM) interface

  • Operating temperature range 0°C to +70°C

  • Compliant with lead-free RoHS6

​Applications:​

  • 200Gb/s InfiniBand HDR systems

  • Other optical links

Details:

Part Number Total Speed Breakout Type SideA Speed Side A Form Factor Side B Speed Side B Form Factor
XHX200-KCCA-xxx 200G 1:1 4x56G PAM4 QSFP56 4x56G PAM4 QSFP56
XHX200-KCCB-xxx 200G 1:2 4x56G PAM4 QSFP56 2x56G PAM4 QSFP56
XHX200-KCCE-xxx 200G 1:1 2x112G PAM4 QSFP112 2x112G PAM4 QSFP112
XHX200-KCCD-xxx 200G 1:2 4x56G PAM4 QSFP56 2x56G PAM4 QSFP112
XHX200-KCCF-xxx 200G 1:4 4x56G PAM4 QSFP56 4x56G PAM4 SFP56



Absolute Maximum Ratings:

Parameter Symbol Min. Max. Unit
Power Supply Voltage VCC -0.5 +3.6 V
Storage Temperature Tc -40 +85 ℃
Relative Humidity RH 0 85 %

Recommended Operating Conditions

Parameter Symbol Min. Typical Max. Unit
Supply Voltage VCC 3.15 3.30 3.45 V
Case Operating Temperature Tca 0 — +70 ℃
Signaling rate per lane — — — 53.125 Gbps
Data Rate Per Lane DR — — 25.78125 Gbps
Fiber Bend Radius Rb 3 — — cm

200G QSFP56 AOC Active Optical Cables Multi-Mode
