USB 2.0 A/F Connector Solder Type with Protective Housing | Electrical Signal Male Connector for Cable Assembly & PCB Interfaces
USB 2.0 A/F Connector Solder Type with Protective Housing | Electrical Signal Male Connector for Cable Assembly & PCB Interfaces
USB 2.0 A/F Connector Solder Type with Protective Housing | Electrical Signal Male Connector for Cable Assembly & PCB Interfaces
USB 2.0 A/F Connector Solder Type with Protective Housing | Electrical Signal Male Connector for Cable Assembly & PCB Interfaces
USB 2.0 A/F Connector Solder Type with Protective Housing | Electrical Signal Male Connector for Cable Assembly & PCB Interfaces
USB 2.0 A/F Connector Solder Type with Protective Housing | Electrical Signal Male Connector for Cable Assembly & PCB Interfaces
USB 2.0 A/F Connector Solder Type with Protective Housing | Electrical Signal Male Connector for Cable Assembly & PCB Interfaces
USB 2.0 A/F Connector Solder Type with Protective Housing | Electrical Signal Male Connector for Cable Assembly & PCB Interfaces
USB 2.0 A/F Connector Solder Type with Protective Housing | Electrical Signal Male Connector for Cable Assembly & PCB Interfaces
USB 2.0 A/F Connector Solder Type with Protective Housing | Electrical Signal Male Connector for Cable Assembly & PCB Interfaces
USB 2.0 A/F Connector Solder Type with Protective Housing | Electrical Signal Male Connector for Cable Assembly & PCB Interfaces
USB 2.0 A/F Connector Solder Type with Protective Housing | Electrical Signal Male Connector for Cable Assembly & PCB Interfaces
USB 2.0 A/F Connector Solder Type with Protective Housing | Electrical Signal Male Connector for Cable Assembly & PCB Interfaces
USB 2.0 A/F Connector Solder Type with Protective Housing | Electrical Signal Male Connector for Cable Assembly & PCB Interfaces
Specifications
Brand Name :
ShuangYi
Model Number :
USB-04F-A6M2A2-10WH
Certification :
ROHS, HF, ISO 9001, ISO 14001, IATF 16959
Place of Origin :
China
MOQ :
1000
Price :
$0.11-0.16 PCS FOB
Payment Terms :
T/T
Supply Ability :
500000 pcs per month
Delivery Time :
8-15 working days
Packaging Details :
Tape and Reel, 1500 per case, 10KG
Structure :
Clamp-mount with protective housing
Material :
Brass (C2680)
Plating :
Copper ≥100 μ″ + Nickel ≥80 μ″
Surface Treatment :
Smooth, no scratches, dents, or deformation
Orientation :
Straight 180°
Application Category :
Wire-to-PCB, power transmission, electronic equipment
Compliance :
RoHS 2.0
Withstand Voltage :
AC 500V/min
Description

Product Description

This USB 2.0 A/F solder-type connector features a robust protective housing and a nickel-plated shielding structure designed for stable electrical and signal transmission. The reinforced LCP insulation provides exceptional heat resistance and flame retardancy, while precision-plated brass terminals ensure consistent conductivity and long-term durability. Its reliable mechanical retention and gold-finished contact interface offer strong mating stability, making it ideal for cable fabrication, power supply assemblies, charging devices, industrial controllers, and various electronic equipment requiring high-quality USB interfaces.

USB 2.0 A/F Connector Solder Type with Protective Housing | Electrical Signal Male Connector for Cable Assembly & PCB InterfacesUSB 2.0 A/F Connector Solder Type with Protective Housing | Electrical Signal Male Connector for Cable Assembly & PCB InterfacesUSB 2.0 A/F Connector Solder Type with Protective Housing | Electrical Signal Male Connector for Cable Assembly & PCB Interfaces

Connector Type USB 2.0 A/F Solder Type with Protective Housing
Structure One-piece shield + insulating base + terminals
Material – Housing LCP, UL94-V0, glass-fiber reinforced
Material – Terminals Brass C2680, T=0.20mm
Material – Inner Shell SUS, T=0.30mm
Material – Outer Shell SPCC, T=0.30mm
Plating – Terminals (Ni) ≥ 50 μ″
Plating – Tin on Solder/Crimp Area ≥ 80 μ″
Plating – Gold on Contact Area G/F
Plating – Inner Shell (Ni) ≥ 30 μ″
Plating – Outer Shell (Ni) ≥ 50 μ″
Mating Force ≤ 35N
Unmating Force ≥ 10N
Durability 1500 cycles, 200 cycles/hour
Flame Rating UL94-V0
Application Cable assembly, PCB board interface, consumer electronics, chargers, data communication devices

Applications

Cable manufacturing lines and USB extension assemblies

Chargers, power banks, adapters

Industrial control equipment and instrumentation

Automotive infotainment and diagnostic devices

Server and communication devices needing stable signal connectors

Consumer electronics and smart appliance interfaces

Precautions

Ensure proper soldering temperature to avoid deformation of the LCP housing.

Avoid excessive mechanical stress on terminals during assembly.

Maintain plating integrity by preventing exposure to corrosive environments.

Verify compatibility with cable OD and PCB layout before mass production.
