Lab Dust Equipment IP6X Sand And Dust Resistance Test Chamber Test Machine
Lab Dust Equipment IP6X Sand And Dust Resistance Test Chamber Test Machine
Lab Dust Equipment IP6X Sand And Dust Resistance Test Chamber Test Machine
Lab Dust Equipment IP6X Sand And Dust Resistance Test Chamber Test Machine
Lab Dust Equipment IP6X Sand And Dust Resistance Test Chamber Test Machine
Lab Dust Equipment IP6X Sand And Dust Resistance Test Chamber Test Machine
Lab Dust Equipment IP6X Sand And Dust Resistance Test Chamber Test Machine
Lab Dust Equipment IP6X Sand And Dust Resistance Test Chamber Test Machine
Specifications
Brand Name :
Zhongli
Model Number :
ZL-6022
Certification :
ISO,CE
Place of Origin :
Guangdong,China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T,L/C,D/A,D/P,Western Union,
Supply Ability :
100 sets per month
Delivery Time :
10~15 days after order confirmed
Packaging Details :
Lab Dust Equipment IP6X Sand And Dust Resistance Test Chamber Test Machine is packaged in wooden case.
Test standards: :
GB4706,GB2423,GB7000.1,IEC60529
Product name :
Lab Dust Equipment IP6X Sand And Dust Resistance Test Chamber Test Machine
Test chamber dimension: :
800*800*800 mm
Dust(talcum powder) concentration: :
2~4kg/m3
Metal screen wire diameter: :
50 Micron
Key words :
Dust Test Machine
Screen line space: :
75 Micron
Warranty: :
12 months
Outer dimension: :
1130*1250*1650mm
Environment temperature and humidity: :
15~45°C, 45~75%RH
Description
Lab Dust Equipment IP6X Sand And Dust Resistance Test Chamber Test Machine
Professional Environment Sand Dust Test Equipment is designed according to GB4706, GB2423, GB7000.1, IEC60529 standards and meets the IPX5 and IPX6 dust test requirements. This dust filter anti-dust removing machine is mainly used for testing control cabinets, household appliances, low voltage electric appliances, automobiles, lamps, motorcycle parts, and other outer shells. Test chamber pressure can be constant and changed, suitable for indoor low concentration dust pollution testing, assessing sample sealing and corrosion degree in this environment.
ZL-6022 Dust test machine.pdf
Specifications
Model Professional Environment Sand Dust Test Equipment
Test chamber dimension 800*800*800mm
Outer dimension 1130*1250*1650mm
Metal screen wire diameter 50um
Screen line space 75um
Environment temperature and humidity 15~45°C, 45~75%RH
Dust (talcum powder) concentration 2~4kg/m3
Test time Dust test time set freely, 0~999.9hr
Test dust Dry talcum powder or portland cement
Test standards GB4706, GB2423, GB7000.1, IEC60529
Power 3ψ 4W+G 380VAC 50HZ
Our Services
Honesty + Professional + Dedication = Value
  • Honesty - Credibility is the soul of the company, operating in good faith to promote enterprise development.
  • Professional - Professional service process, professional quality services.
  • Dedication - Will spare no effort to serve for Customer.
  • Value - Take the customer demand as the guidance, provide super value service.
Lab Dust Equipment IP6X Sand And Dust Resistance Test Chamber Test Machine Lab Dust Equipment IP6X Sand And Dust Resistance Test Chamber Test Machine
Dongguan Zhongli Instrument Technology Co., Ltd is known as sophisticated manufacturing on environmental and physical equipment with TOP quality. We own machine controller software patents and CE certificates.
Advantage Service
  • We have R&D, designing department which can not only provide technological machines but also can satisfy special customized needs of our clients.
  • Over 50 years' manufacturing experience, advanced machine and sophisticated handcraft.
  • There are TWO laboratories in our factory: Environmental laboratory and Physical laboratory.
  • Our factory have adequate stock monthly, which can meet customers' urgent needs.
  • Annual sales over 1,000,000USD; 30,000㎡ manufacturing base, equipped with 120 technicians, we are capable to take large budget project.
Technical Support
  • SUS Stainless plate is cut by advanced laser machine which can ensure accuracy; All machine appearance is anti-rust electrostatic painting.
  • Imported electronic components: ABB/Saginomiya/Danfoss/Emkarate/Omron and imported compressor: BOEK/TECUMSEH, which can keep the machine's service life over 10 years.
