20 Station 1.5mm Highway Guardrail Roll Forming Machine Liming
20 Station 1.5mm Highway Guardrail Roll Forming Machine Liming
Specifications
Brand Name :
LIMING
Model Number :
LM-highway 5.2
Certification :
CE、ISO
Place of Origin :
China
MOQ :
1
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
80set/Year
Delivery Time :
40 work days
Packaging Details :
Nude、Anti-dust film, Anti-rust cloth
Warranty :
1.5 Years
Weight :
8 Ton
Voltage :
380V.50HZ.3Phase
Tickness of coil :
1.5mm-3mm
Main power :
18.5 KW
Type :
Highway guardrail crash barrier roll forming machine
Structure :
350H beam
roduction Capacity :
10-30M/Min
Material of Roller :
Gcr12, Quench HRC58-62 Plated Chrome
Dimension(L*W*H) :
15m*2m*1.8m
Description

Industry-Leading Technology, 20-Station Highway Guardrail Machine LIMing

Highway guardrail machine is used to produce high-speed guardrail board equipment

The highway guardrail machine is composed of uncoiling device, punching machine, forming host, fixed-length cutting, and automatic baler. The whole machine is controlled by PLc Panasonic electronic control, which is simple to operate and can help you save a lot of labor costs.

technical parameter of Industry-Leading Technology, 20-Station Highway Guardrail Machine LIMing

Equipment presidents About 18m Width 0.6m Height 1.2m
Equipment weight About 18 tons
Transmission way Chain transmission or gear box transimission
roller material high grade 45#steel ,hard chrome 0.05 heated,hard plated and quenched
shaft material high grade 45#steel ,hard chrome 0.05 heated,hard plated and quenched
Main power 18.5 KW
Pump power 7.5KW
Cutter material high grade GR12
row station 20station
Material thickness 1.5-3mm
Speed 10 ~ 15 meters per minute
Warranty 2year

The highway guardrail machine also adopts the Siemens motor and gear box transmission method to ensure the sufficient power of the highway guardrail machine. It can help you produce high-speed guardrail board profiles with different thicknesses. At the same time, the high-speed guardrail board produced by the highway guardrail machine is accurate in size. , Easy to install can help you quickly open the market to win market competitiveness.

Highway guardrail machines need customized production. You only need to provide drawings or dimensions. Our design team with more than 20 years of manufacturing experience will help you design multiple sets of equipment solutions for you to choose. After you choose, we will let us The professional manufacturing team will manufacture a high-precision road guardrail machine for you to help you produce. Please rest assured that our assembled road guardrail machines have been produced and tested to ensure that the size reaches you accurately. You can directly For production use,

20 Station 1.5mm Highway Guardrail Roll Forming Machine Liming20 Station 1.5mm Highway Guardrail Roll Forming Machine Liming20 Station 1.5mm Highway Guardrail Roll Forming Machine Liming20 Station 1.5mm Highway Guardrail Roll Forming Machine Liming
