Galvanized 140mm Rolling Shutter Door Forming Machine
Galvanized 140mm Rolling Shutter Door Forming Machine
Specifications
Brand Name :
LIMING
Model Number :
LM-RSD9
Certification :
CE、BV、ISO
Place of Origin :
China
MOQ :
1
Price :
Negotiation
Payment Terms :
T/T, L/C, D/A, D/P
Supply Ability :
450set/Year
Delivery Time :
40 work days
Packaging Details :
Nude、Anti-dust film, Anti-rust cloth
Raw material  :
Galvanized coils yield strength ≤G250MPa
After-sales Service Provided :
Online support, Free spare parts, Field installation, commissioning
Feeding width :
122mm or According to client’s requirement
Voltage :
380V.50HZ.3Phase
thickness :
0.7-2.0mm
Working speed :
8-15 m/min
Dimension(L*W*H) :
6500mm*800mm*1200mm(depends on final design)
Forming roller station :
12 Stations
Description

Galvanized 140mm Rolling Shutter Door Forming Machine

The galvanized roller shutter door curtain sheet produced by the Galvanized 140mm Rolling Shutter Door Forming Machine can resist weak corrosive media such as air, steam and water, and has the advantage of not being easy to rust. Importantly, the galvanized roller shutter door curtain sheet produced by the Galvanized 140mm Rolling Shutter Door Forming Machine also has a fireproof effect.

The Galvanized 140mm Rolling Shutter Door Forming Machine is composed of curtain plates, rolling elements, guide rails, electric drive devices, etc.

The Galvanized 140mm Rolling Shutter Door Forming Machine has the characteristics of good rigidity and excellent sealing performance. It is an essential fire prevention facility in modern high-rise buildings. In addition to the functions of ordinary doors, fire doors also have the functions of preventing fire, smoke, restraining the spread of fire and protecting personnel from evacuation.

Galvanized 140mm Rolling Shutter Door Forming Machine is widely used in high-rise buildings, large shopping malls and other crowded occasions.

Technical Parameters Of Galvanized 140mm Rolling Shutter Door Forming Machine

No. Type Specification
1 Row Material Type Colored steel plate, Galvanized board, Aluminum plate ect
Feeding width 122mm or According to client’s requirement
Thickness 0.7-0.8mm
2 Main Body Forming roller station 12 Stations
Straight roller station 3 Stations ( Up layer 2 rollers , down layer 3 rollers )
Diameter of shaft 40mm
Shaft material High grade 45# steel
Roller material High grade 45# steel , hard treatment and polishing ( plated chrome on surface )
Main body frame Whole set of square pipe
Frame thickenss 14 mm
Working speed 8-15 m/min
Size (L*W*H) About 6800*850*1310mm
Weight About 2.5 tons
3 Power Motor power 3 kw
Hydraulic power 3 kw
Voltage 380V 50Hz 3phases or Customerization
Drving Way By Gear
4 PLC Control System Language English and Chinese
Brand Of PLC Delta brand ( Touch Screen )
Operation Manual and Automatic ( Two Type )
Transducer Delta brand
5 Cutting Device Cutting Type Hydraulic Cutting
Blade of Cutting Cr12 , quenching treatment
Cutting Tolerance ± 1mm

Galvanized 140mm Rolling Shutter Door Forming Machine
