PP Biaxial Geogrid 1515 For Soft Foundation Reinforcing Of Highway And Railway
PP Biaxial Geogrid 1515 For Soft Foundation Reinforcing Of Highway And Railway
PP Biaxial Geogrid 1515 For Soft Foundation Reinforcing Of Highway And Railway
PP Biaxial Geogrid 1515 For Soft Foundation Reinforcing Of Highway And Railway
PP Biaxial Geogrid 1515 For Soft Foundation Reinforcing Of Highway And Railway
PP Biaxial Geogrid 1515 For Soft Foundation Reinforcing Of Highway And Railway
PP Biaxial Geogrid 1515 For Soft Foundation Reinforcing Of Highway And Railway
PP Biaxial Geogrid 1515 For Soft Foundation Reinforcing Of Highway And Railway
PP Biaxial Geogrid 1515 For Soft Foundation Reinforcing Of Highway And Railway
PP Biaxial Geogrid 1515 For Soft Foundation Reinforcing Of Highway And Railway
Specifications
Brand Name :
Briture
Model Number :
PP Biaxial Geogrid
Certification :
CE、ISO
Place of Origin :
China
MOQ :
The MOQ of PP Biaxial Geogrid is 20000m2
Price :
The price of PP Biaxial Geogrid is USD 0.4-1.4/m2 FOB Shanghai
Payment Terms :
The payment of PP Biaxial Geogrid is L/C, T/T
Supply Ability :
2500MT/year
Delivery Time :
18-30 work days
Packaging Details :
3.95mX 50m in a roll
Product Name :
PP Biaxial Geogrid 1515
PP Biaxial Geogrid Width :
The width is 3.95m
PP Biaxial Geogrid Length :
The length is 50-100m
PP Biaxial Geogrid Color :
Black
PP Biaxial Geogrid Mesh Size :
36X34mm
PP Biaxial Geogrid Application :
Soft foundation reinforcing of Highway And Railway
Description

PP Biaxial Geogrid 1515 For Soft foundation reinforcing of Highway And Railway

PP Biaxial Geogrid Introduction:

PP Biaxial Plastic Geogrid is used PP as its raw material, produced through extruding, punching, heating, longitudinal stretching, transverse stretching.

PP Biaxial Geogrid Performance:

The PP biaxial geogrid have high tensile strength at both longitudinal & transverse dire.

PP Biaxial Geogrid Application:

Soft foundation reinforcing for highway,railway, Slop protecting projects, landfill side.
PP Biaxial Geogrid Function:
1. Improve the bearing capacity of foundation;
2. Preventing cracking and subsiding;
3. Convenient to construct, reducing cost and maintaining expense

PP Biaxial Geogrid Specification:

Index properties
Test Method
Units
MD Values
TD Values
Polymer - - pp -
Carbon Black Min ASTM D 4218 % 2 -
Tensile strength @2% Strain ASTM D 6637 KN/m 5 5
Tensile strength @5% Strain ASTM D 6637 KN/m 7 7
Ultimate tensile strength ASTM D 6637 KN/m 15 15
Strain @ Ultimate strength ASTM D 6637 % 13 13

Junction Efficiency GRI GG2 % 90 90
Overall Flexural Rigidity ASTM D 1388 mg-cm 690,000 -
Aperture Stability COE Method mm-N/deg 646 -
Aperture Dimensions - mm 38 36
Minimum Rib Thickness ASTM D 1777 mm 0.9 0.7
Roll Width - m 3.95 -
Roll Length - m 50 -
Roll Weight - kg 38 -

PP Biaxial Geogrid Packing:

The roll is 3.95mx50m. And 52140M2(264 rolls) in a 40HQ.

Certification:

PP Biaxial Geogrid 1515 For Soft Foundation Reinforcing Of Highway And Railway
