Polypropylene Biaxial Terram Geotextile Geogrid For Road Base Construction
Polypropylene Biaxial Terram Geotextile Geogrid For Road Base Construction
Polypropylene Biaxial Terram Geotextile Geogrid For Road Base Construction
Polypropylene Biaxial Terram Geotextile Geogrid For Road Base Construction
Polypropylene Biaxial Terram Geotextile Geogrid For Road Base Construction
Polypropylene Biaxial Terram Geotextile Geogrid For Road Base Construction
Polypropylene Biaxial Terram Geotextile Geogrid For Road Base Construction
Polypropylene Biaxial Terram Geotextile Geogrid For Road Base Construction
Polypropylene Biaxial Terram Geotextile Geogrid For Road Base Construction
Polypropylene Biaxial Terram Geotextile Geogrid For Road Base Construction
Polypropylene Biaxial Terram Geotextile Geogrid For Road Base Construction
Polypropylene Biaxial Terram Geotextile Geogrid For Road Base Construction
Specifications
Brand Name :
Briture
Model Number :
PPBG30-30
Certification :
CE
Place of Origin :
China
MOQ :
26860m2
Price :
USD0.68-0.73/m2 FOB Qingdao port
Payment Terms :
L/C, T/T
Delivery Time :
about 10days
Packaging Details :
3.95x50m each roll
Color :
Black
Width :
3.95 or 5.95m
Length :
50m
Application :
highway, railway,Slop protecting projects, landfill side
Material :
Polypropylene
Mesh size :
36x38mm
Tensile strength :
15-40kN/m
Description

Introduction:

PP Biaxial Plastic Geogrid is used PP as its raw material, produced through extruding, punching, heating, longitudinal stretching, transverse stretching.

Performance:

High tensile strength at both longitudinal & transverse direction

Application:

Soft foundation reinforcing for highway, railway,Slop protecting projects, landfill side

Speicifation for PPBG1515:

Index Properties Test Method Units MD Values TD Values
Polymer PP
Minimum Carbon Black ASTM D 4218 % 2
Tensile Strength @ 2% Strain ASTM D 6637 kN/m 5 5
Tensile Strength @ 5% Strain ASTM D 6637 kN/m 7 7
Ultimate Tensile Strength ASTM D 6637 kN/m 15 15
Strain @ Tensile Strength ASTM D 6637 % 13 13
Structural Integrity
Junction Efficiency GRI GG2 % 90 90
Overall Flexural Rigidity ASTM D 1388 mg-cm 690,000
Aperture Stability COE Method mm-N/deg 646
Dimensions
Aperture Dimensions - mm 38 36
Min. Rib Thickness ASTM D 1777 mm 0.9 0.7
Roll Width - m 3.95
Roll Length - m 50
Roll Weight - kg 38

Speicifation for PPBG2020:

Index Properties Test Method Units MD Values TD Values
Polymer PP
Minimum Carbon Black ASTM D 4218 % 2
Tensile Strength @ 2% Strain ASTM D 6637 kN/m 7 7
Tensile Strength @ 5% Strain ASTM D 6637 kN/m 14 14
Ultimate Tensile Strength ASTM D 6637 kN/m 20 20
Strain @ Tensile Strength ASTM D 6637 % 13 13
Structural Integrity
Junction Efficiency GRI GG2 % 90 90
Overall Flexural Rigidity ASTM D 1388 mg-cm 1,090,000
Aperture Stability COE Method mm-N/deg 707
Dimensions
Aperture Dimensions - mm 39 39
Min. Rib Thickness ASTM D 1777 mm 1.3 1.0
Roll Width - m 3.95
Roll Length - m 50
Roll Weight - kg 50

Speicifation for PPBG2525:

Index Properties Test Method Units MD Values TD Values
Polymer PP
Minimum Carbon Black ASTM D 4218 % 2
Tensile Strength @ 2% Strain ASTM D 6637 kN/m 9 9
Tensile Strength @ 5% Strain ASTM D 6637 kN/m 17 17
Ultimate Tensile Strength ASTM D 6637 kN/m 25 25
Strain @ Tensile Strength ASTM D 6637 % 13 13
Structural Integrity
Junction Efficiency GRI GG2 % 90 90
Overall Flexural Rigidity ASTM D 1388 mg-cm
Aperture Stability COE Method mm-N/deg
Dimensions
Aperture Dimensions - mm 39 39
Min. Rib Thickness ASTM D 1777 mm 1.8 1.5
Roll Width - m 3.95
Roll Length - m 50
Roll Weight - kg 58

Speicifation for PPBG3030:

Index Properties Test Method Units MD Values TD Values
Polymer PP
Minimum Carbon Black ASTM D 4218 % 2
Tensile Strength @ 2% Strain ASTM D 6637 kN/m 10.5 10.5
Tensile Strength @ 5% Strain ASTM D 6637 kN/m 21 21
Ultimate Tensile Strength ASTM D 6637 kN/m 30 30
Strain @ Tensile Strength ASTM D 6637 % 13 13
Structural Integrity
Junction Efficiency GRI GG2 % 90 90
Overall Flexural Rigidity ASTM D 1388 mg-cm 3,930,000
Aperture Stability COE Method mm-N/deg 1432
Dimensions
Aperture Dimensions - mm 39 39
Min. Rib Thickness ASTM D 1777 mm 2.1 1.8
Roll Width - m 3.95
Roll Length - m 50
Roll Weight - kg 68

Speicifation for PPBG4040:

Index Properties Test Method Units MD Values TD Values
Polymer PP
Minimum Carbon Black ASTM D 4218 % 2
Tensile Strength @ 2% Strain ASTM D 6637 kN/m 14 14
Tensile Strength @ 5% Strain ASTM D 6637 kN/m 28 28
Ultimate Tensile Strength ASTM D 6637 kN/m 40 40
Strain @ Tensile Strength ASTM D 6637 % 13 13
Structural Integrity
Junction Efficiency GRI GG2 % 90 90
Overall Flexural Rigidity ASTM D 1388 mg-cm 11,480,000
Aperture Stability COE Method mm-N/deg
Dimensions
Aperture Dimensions - mm 39 39
Min. Rib Thickness ASTM D 1777 mm 2.1 1.6
Roll Width - m 3.95
Roll Length - m 50
Roll Weight - kg 96
