Specifications
Model NO. :
SF-318
Condensor Design :
latest Exclusively for Refrigeration Unit
Sealing Technology :
Patented O Sealing Technology
Design Base Environment :
45 Degree C
Durability Range :
The Highest Level
Maintenance :
Lower The Cost of Maintanance
Transport Package :
Carton Filled with Paper Honeycomb
Trademark :
SNOWFALL
Origin :
Guangzhou, China
HS Code :
8418692090
Supply Ability :
300 Sets Per Month
Condition :
New
Service :
OEM
Installation :
Front, Roof, Under Mounting Type
Electric :
Optional Electric Standby System
Colour :
White
Fan Material :
Aluminium Alloy
Customization :
Available | Customized Request
Description

Patented O Sealing Technology Low MOQ Refrigeration Unit for Truck Body Electric Optional
Patented O Sealing Technology Low MOQ Refrigeration Unit for Truck Body Electric Optional
Patented O Sealing Technology Low MOQ Refrigeration Unit for Truck Body Electric Optional
Patented O Sealing Technology Low MOQ Refrigeration Unit for Truck Body Electric Optional
Patented O Sealing Technology Low MOQ Refrigeration Unit for Truck Body Electric Optional
SF-318
Suitable for 3~8m of mini refrigerated and frozen models to drive the refrigerating unit by automobile engine
It is the first choice for supermarket and catering distribution. Its refrigeration performance is very stable and reliable. SNOWFALL recommends you choose between a classic engine drive unit and a brand new backup built-in unit. Covering all container volumes, one or more of this series will meet your needs.
Driven transport refrigerating unit SF-318 is a reliable refrigerating unit for miniature thermal insulation cars with the dimensions of 3~-8m.
Features:
1. Optional DC 12V or 24V for your choice.
2.The whole transport refrigerating unit is light and compact, the condenser is in front, and the evaporator can be installed as required.
3.This series of models fully covers the freezing capacity ranging from 3 m to 8 m and accurately matches its freezing volume from per square meter.
4.Each SNOWFALL will be featured with low cost, low maintenance, low noise, energy saving and environmental protection.
Unit Model SF-318
Applicable Temperature 20 °C ~ - 5 °C
Cooling Capacity Environmental Temperature 35 °C
0 °C 1800Kcal/2093W/7142BTU
Compressor Model SD5S14
Displacement(cc/r) 138
Condenser Type P.F.
Fan Type Axial Fan
Number of Fan 1 Fans * 800m ³/h
Voltage DC 12V / DC 24V
Evaporator Type Inner screw tube and aluminium fin
Fan Type Axial Fan
Number of Fan 1 Fans * 1000m ³/h
Voltage DC 12V / DC 24V
Power Comsumption ≤22A(DC 12V) ≤11A(DC 24V)
Refrigerant R-134a
Structure Split direct drive unit
Electrical Standby System (optional part) AC 220V / AC 380V/ 415V
Dimensions(mm) & Net Weight(kg) SF-318 Evaporator 790*590*170 18.34kg
SF-318 Condenser 800*480*180 17.88kg
SF-T318 Condenser 870*700*150 21.33kg
