White Sealing Technology Refrigeration Unit for Refrigeration/Freezer Truck SF-328
White Sealing Technology Refrigeration Unit for Refrigeration/Freezer Truck SF-328
White Sealing Technology Refrigeration Unit for Refrigeration/Freezer Truck SF-328
White Sealing Technology Refrigeration Unit for Refrigeration/Freezer Truck SF-328
White Sealing Technology Refrigeration Unit for Refrigeration/Freezer Truck SF-328
White Sealing Technology Refrigeration Unit for Refrigeration/Freezer Truck SF-328
White Sealing Technology Refrigeration Unit for Refrigeration/Freezer Truck SF-328
White Sealing Technology Refrigeration Unit for Refrigeration/Freezer Truck SF-328
White Sealing Technology Refrigeration Unit for Refrigeration/Freezer Truck SF-328
White Sealing Technology Refrigeration Unit for Refrigeration/Freezer Truck SF-328
White Sealing Technology Refrigeration Unit for Refrigeration/Freezer Truck SF-328
White Sealing Technology Refrigeration Unit for Refrigeration/Freezer Truck SF-328
Specifications
Model NO. :
SF-328
Condenser Design :
Lastest Exclusively for Refrigeration Unit
Sealing Technology :
Patented O Sealing Technology
Design Base Environment :
45 Degree C
Durability Range :
The Highest Level
Maintenance :
Lower The Cost of Maintance
Transport Package :
Carton Filled with Paper Honeycomb
Trademark :
SNOWFALL
Origin :
Guangzhou, China
HS Code :
8418692090
Supply Ability :
400 Sets Per Month
Certification :
ISO9000
Service :
OEM
Installation :
Front, Roof, Under Mounting Type
Electric :
Optional Electric Standby System
Colour :
White
Fan Material :
Aluminium Alloy
Customization :
Available | Customized Request
Description
Trcuk refrigeration unit SF-328
1) keep your goods fresh & cooling
2)compressor:SD5H14
3)Automaticaly hot air defrost
White Sealing Technology Refrigeration Unit for Refrigeration/Freezer Truck SF-328

White Sealing Technology Refrigeration Unit for Refrigeration/Freezer Truck SF-328
Unit Model SF-328
Applicable Temperature 15 °C ~ - 20 °C
Cooling Capacity Environmental Temperature 35 °C
0 °C 2800Kcal/3256W/11109BTU
-18 °C 175Kcal/2035W/6943BTU
Compressor Model SD5S14
Type Swash plate type
Displacement(cc/r) 138
Ludricating POE
Condenser Type P.F.
Fan Type Axial Fan
Number of Fan 2 Fans * 1000m ³/h
Voltage DC 12V / DC 24V
Evaporator Type Inner screw tube and aluminium fin
Fan Type Axial Fan
Number of Fan 2 Fans * 1000m ³/h
Voltage DC 12V / DC 24V
Power Comsumption ≤33A(DC 12V) ≤16.5A(DC 24V)
Throttle Type External equalizer expansion valve
Refrigerant R-134a/R-404a
Defrost Type Automatically hot air defrost
Structure Split direct drive unit
Electrical Standby System (optional part) AC 220V / AC 380V/ 415V
Dimensions(mm) & Net Weight(kg) SF-328 Evaporator 1270*580*170 31.63kg
SF-328 Condenser 1080*430*350 30kg
SF-T328 Condenser 1000*900*170 33.87kg
SF-U328 Condenser 890*270*380 25.03kg
