Under Mounting Type Refrigeration Unit DC12V 24V for Refrigerated Trucks
Under Mounting Type Refrigeration Unit DC12V 24V for Refrigerated Trucks
Under Mounting Type Refrigeration Unit DC12V 24V for Refrigerated Trucks
Under Mounting Type Refrigeration Unit DC12V 24V for Refrigerated Trucks
Under Mounting Type Refrigeration Unit DC12V 24V for Refrigerated Trucks
Under Mounting Type Refrigeration Unit DC12V 24V for Refrigerated Trucks
Under Mounting Type Refrigeration Unit DC12V 24V for Refrigerated Trucks
Under Mounting Type Refrigeration Unit DC12V 24V for Refrigerated Trucks
Under Mounting Type Refrigeration Unit DC12V 24V for Refrigerated Trucks
Under Mounting Type Refrigeration Unit DC12V 24V for Refrigerated Trucks
Under Mounting Type Refrigeration Unit DC12V 24V for Refrigerated Trucks
Under Mounting Type Refrigeration Unit DC12V 24V for Refrigerated Trucks
Specifications
Condensor Design :
Latest Exclusively for Refrigeration Unit
Sealing Technology :
Patented O Sealing Technology
Design Base Environment :
45 Degree C
Durability Range :
The Highest Level
Maintenance :
Lower The Cost of Maintance
Transport Package :
Carton Filled with Paper Honeycomb
Trademark :
SNOWFALL
Origin :
Guangzhou, China
HS Code :
8418692090
Supply Ability :
350 Sets Per Month
Condition :
New
Service :
OEM
Installation :
Front, Roof, Under Mounting Type
Electric :
Optional Electric Standby System
Colour :
White
Fan Material :
Aluminium Alloy
Customization :
Available | Customized Request
Description


Under Mounting Type Refrigeration Unit DC12V 24V for Refrigerated Trucks
Under Mounting Type Refrigeration Unit DC12V 24V for Refrigerated Trucks
Under Mounting Type Refrigeration Unit DC12V 24V for Refrigerated Trucks
Under Mounting Type Refrigeration Unit DC12V 24V for Refrigerated Trucks
Under Mounting Type Refrigeration Unit DC12V 24V for Refrigerated Trucks
Good Performance Refrigeration Unit FOR Refrigerated Trucks
Feature:
  1. Optional DC 12V or 24V for you to choose, and backup electric refrigeration system DC220V/DC380V optional installation.
  2. The whole transport refrigerating unit is light and compact, the condenser is in front, and the evaporator can be installed as required.
  3. This series of models fully covers the refrigerated capacity ranging from 14m to 49 m and accurately matches its refrigerated volume from per square meter.
Each SNOWFALL will be featured with low cost, low maintenance, low noise, energy saving and environmental protection.
  1. Each SNOWFALL will be featured with low cost, low maintenance, low noise, energy saving and environmental protection.
Unit Model SF-600
Applicable Temperature(ºC) +15 ~ -20
Cooling Capacity Environmental temperature 35ºC
0°C 6000Kcal/ 6978W/ 23809BTU
-20°C 3700Kcal/ 4303W/ 14682BTU
Compressor Model QP-21
Displacement(cc/r) 200 cc
Condenser Type P.F.
Fan Type Axial fan
Number of Fan 2Fans×1100m3/h total 2200m3/h
Voltage DC12V/DC24V
Evaporator Type Inner screw tube and aluminum fin
Fan Type Axial fan
Number of Fan 3Fans×800m3/h total2400m3/h
Voltage DC12V/DC24V
Power Consumption ≤ 48A(DC12V) ≤ 29.6A(DC24V)
Refrigerant R-404a
Defrost Type Automatically hot air defrost
Structure Split direct drive unit
Dimensions(mm) /Net weight(kg) SF-600 Evaporator 1250×490×360 39.5kg
SF-600 Condenser 1410×630×495 30kg





Our products have been exported to many countries for years and enjoyed great reputation.


Our oversea markets are as follows: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, MID East, Eastern Asia, Western Europe etc
