Frozen Food Transport Cooling Units Refrigerated Chiller Unit Front Installation
Frozen Food Transport Cooling Units Refrigerated Chiller Unit Front Installation
Frozen Food Transport Cooling Units Refrigerated Chiller Unit Front Installation
Frozen Food Transport Cooling Units Refrigerated Chiller Unit Front Installation
Frozen Food Transport Cooling Units Refrigerated Chiller Unit Front Installation
Frozen Food Transport Cooling Units Refrigerated Chiller Unit Front Installation
Frozen Food Transport Cooling Units Refrigerated Chiller Unit Front Installation
Frozen Food Transport Cooling Units Refrigerated Chiller Unit Front Installation
Frozen Food Transport Cooling Units Refrigerated Chiller Unit Front Installation
Frozen Food Transport Cooling Units Refrigerated Chiller Unit Front Installation
Specifications
Colour :
White
Fan Material :
Aluminium Alloy
Condensor Design :
latest Exclusively for Refrigeration Unit
Sealing Technology :
Patented O Sealing Technology
Durability Range :
The Highest Level
Maintenance :
Lower The Cost of Maintance
Transport Package :
Carton
Trademark :
SNOWFALL
Origin :
Guangzhou, China
HS Code :
8418692090
Supply Ability :
5000 Sets/ Year
Type :
Cooling System
Application Fields :
Refrigerated Trucks
Condition :
New
Service :
OEM
Installation :
Front, Roof, Under Mounting Type
Electric :
Optional Electric Standby System
Customization :
Available | Customized Request
Description
Truck refrigeration units SF-318

1)latest design condensor,
2) O good sealing,
3)Compressor Model:SD5H14
4)R-134a refrigera

Trcuk refrigeration unit SF-318
Main specification

1.Applicable Temperature

2.Cooling Capacity :0°C 1800Kcal/2093W/714BTU

3.Compressor
1)Model:SD5H14
2)Displacement(cc/r) :138

4.Condenser:
1).Type:P.F.
2)Fan Type:Axial fan
3)Number of fan:1fan*800m3/h
4)Voltage:DC12V/DC24V

5.Evaporator:

1)Type:inner screw tube and aluminum fin

2)Fan type:Axial fan

3)Number of fan 1fan*1000m3/h

4)Voltage:DC12V/DC24V



6.Power consuption:Between 22A(DC12V)and 11A(DC24V)

7.Refrigerant:R-134a

8.Structure:Spilt direct drive unit

9.Dimensions(mm)/Net weight:of Condenser :800*480*180mm(31"*19"*7")/17.88kgs

10.Dimensions(mm)/Net weight:of Evaporator :790*590*170mm( 31"*23"*6.7")/18.34kgs

Our products have been exported to many countries for years and enjoyed great reputation .

Our oversea markets are as follows:North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe etc.



Frozen Food Transport Cooling Units Refrigerated Chiller Unit Front InstallationFrozen Food Transport Cooling Units Refrigerated Chiller Unit Front InstallationFrozen Food Transport Cooling Units Refrigerated Chiller Unit Front InstallationFrozen Food Transport Cooling Units Refrigerated Chiller Unit Front InstallationFrozen Food Transport Cooling Units Refrigerated Chiller Unit Front Installation
Unit Model SF-318
Applicable Temperature 20 °C ~ - 5 °C
Cooling Capacity Environmental Temperature 35 °C
0 °C 1800Kcal/2093W/7142BTU
Compressor Model SD5S14
Displacement(cc/r) 138
Condenser Type P.F.
Fan Type Axial Fan
Number of Fan 1 Fans * 800m ³/h
Voltage DC 12V / DC 24V
Evaporator Type Inner screw tube and aluminium fin
Fan Type Axial Fan
Number of Fan 1 Fans * 1000m ³/h
Voltage DC 12V / DC 24V
Power Comsumption ≤22A(DC 12V) ≤11A(DC 24V)
Refrigerant R-134a
Structure Split direct drive unit
Electrical Standby System (optional part) AC 220V / AC 380V/ 415V
Dimensions(mm) & Net Weight(kg) SF-318 Evaporator 790*590*170 18.34kg
SF-318 Condenser 800*480*180 17.88kg
SF-T318 Condenser 870*700*150 21.33kg
