Specifications
Display :
Optional LCD display
Output :
4...20 mA
Power Supply :
24 V DC
Supply Ability :
100PCS/Month
Place of Origin :
China
Payment Terms :
L/C,D/A,T/T,D/P
Repeatability :
10-95%
MOQ :
1Set
Features :
Integrated Temperature Transmitter
Environmental Temperature :
0~50℃
Model Number :
QW-SLS78
Price :
Negotiable
Brand Name :
QINWEIYB
Packaging Details :
Carton or wooden box
Measure Range :
0-100mpa
Connector :
Thread
Delivery Time :
5-8 work days
Sensor Length :
500mm(19.68in)
Outputsignal :
4-20mA
Description

The hygienic temperature transmitter is a temperature measurement instrument specially designed for industries with extremely high hygiene requirements such as food, and bioengineering.

Core advantages:
  • Complies with hygiene and safety standards, with no risk of medium contamination.
  • Supports online cleaning and sterilization, making maintenance convenient.
  • Features a quick-install structure for efficient installation and disassembly.
  • High precision and good stability.
The core differences between it and general-purpose temperature transmitters
Comparison dimension Sanitary temperature transmitter General industrial temperature transmitter
International certification Must pass 3-A, EHEDG, FDA and other sanitary certifications Usually only requires explosion-proof, CE and other general certifications
Surface roughness Ra ≤ 0.4μm, mirror-polished Ra around 1.6μm, industrial-level polishing is sufficient
Process connection Clamp, Varivent, DIN 11851 and other sanitary interfaces Threading, flange and other general interfaces
Disassembly and cleaning Supports quick disassembly, supports CIP (cleaning in place)/SIP (sterilization in place) Usually requires shutdown for disassembly
Structural design No dead corners, easy to drain May have dead corners and liquid accumulation risks
Material requirements Contact parts are 316L stainless steel, with material certificates 304 and 316L are both acceptable
Application scenarios
  • Food and Beverage: Pasteurization of milk, fermentation of beer, sterilization of fruit juice, CIP cleaning temperature monitoring.
  • Biotechnology: Cell culture, bioreactor.
  • Fine Chemicals: Production of chemical products with cleanliness requirements.

The hygienic temperature transmitter is an expert "born for cleanliness". Its selection logic is very clear: when your application belongs to industries such as food, beverage, and bioengineering that have strict hygiene regulations, it is the only choice.
