High-Sensitivity Portable Dust Monitor Built-In Lithium Battery
High-Sensitivity Portable Dust Monitor Built-In Lithium Battery
High-Sensitivity Portable Dust Monitor Built-In Lithium Battery
High-Sensitivity Portable Dust Monitor Built-In Lithium Battery
High-Sensitivity Portable Dust Monitor Built-In Lithium Battery
High-Sensitivity Portable Dust Monitor Built-In Lithium Battery
High-Sensitivity Portable Dust Monitor Built-In Lithium Battery
High-Sensitivity Portable Dust Monitor Built-In Lithium Battery
Specifications
Model Number :
YR-PF100
Measurement Error :
<+20% (mg/m³)
Delivery Time :
5-8 work days
Customization Services :
OEM, ODM, OBM, Software Reengineering
Type :
Portable Dust PM Monitor
Packaging Details :
Carton or wooden box
Material :
ABS Plastic
Price :
Negotiable
Target Gas :
Dust
Product Name :
Portable Dust Concentration Monitor
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Power :
Electric
Alarm Mode :
Light + Sound + Vibration
Accuracy Level :
High Precision
Brand Name :
QINWEIYB
Place of Origin :
China
MOQ :
1Set
Description

This device is a portable pump-type dust detector that uses laser light scattering detection technology. With an integrated handheld gun-style design, it can simultaneously and in real time measure concentrations of TSP, PM10, and PM2.5 particles. Equipped with a built-in lithium battery, it is ideal for on-site rapid inspections and temporary monitoring point assessments, and is widely used for dust detection in industrial workshops, construction sites, and factory areas.

Product Specifications
Target Gas Dust
Accuracy Level High Precision
Material ABS Plastic
Customization Services OEM, ODM, OBM, Software Reengineering
Model YR-PF100
Power Electric
Measurement Range Total Suspended Particulates 0–100.0 (mg/m³); PM10 0–20.00 (mg/m³); PM2.5 0–10.00 (mg/m³)
Type Portable Dust PM Monitor
Alarm Mode Light + Sound + Vibration
Warranty 1 Year
Origin China
Product Name Portable Dust Concentration Monitor
Measurement Error <+20% (mg/m³)
Operating Environment -10°C to 50°C, 20%–70% Relative Humidity
Communication Method RS485 / 4–20 mA
Alarm Settings Low: 4.0 mg/m³; High: 8.0 mg/m³ (adjustable)
Detection Method Pump-Drawn
Dimensions 165 mm × 85 mm × 46 mm
Response Time <6 seconds
Product Features
  • High Precision: Ensures accurate dust concentration measurement for reliable air quality assessment.
  • Portable Design: Compact and lightweight, ideal for mobile use in various environments.
  • Durable ABS Housing: Resistant to wear, delivering long-lasting performance.
  • 1-Year Warranty: Peace of mind with added assurance of product reliability.
  • Wide Application: Perfectly suited for industrial, environmental, and public health monitoring.
Applicable scenarios
  • Industrial workshop dust inspection: sanding, wood processing, metalworking, powder production lines
  • Construction site and aggregate yard dust sampling inspections
  • Environmental enforcement temporary on-site monitoring, unorganized emission surveys at industrial sites
  • Tunnel, underground space, and indoor factory air quality testing
  • Warehouse, feed mill, and pharmaceutical plant dust risk inspections
