Specifications
customized support :
OEM, ODM
MOQ :
1
Control mode :
PLC program
Voltage :
220V Electrical Equipment
Protection Class :
/
Brand Name :
HAIDA
Place of Origin :
Guangdong, China
Power supply :
220± 10% V /50Hz
Test stations :
Six stations (simultaneous control)
Operating mode :
Touch screen
Application :
Tissue Paper Test
Feature :
The dwell time for forward and reverse rotation can be set
Type :
Testing Machine
Test times :
1 to 99,999,999 times can be set
warranty :
1 Year
Test speed :
1 to 10 times per minute
power :
220± 10% V /50Hz
Test Angle :
0-360° can be set
Description
Sanitary Tapware Thermostatic Valve Performance Test Machine

The equipment is designed according to the requirements of ASSE1016-2017 and EN1111-2017 standard terms and conditions. It performs thermostatic valve water temperature stability tests, cold water loss of supply temperature tests, and mechanical life and performance tests.

Sanitary Tapware Thermostatic Valve Performance Test Machine Valve Performance Tester

The equipment comes with a water tank but uses heating and refrigeration systems to control hot and cold water temperatures. Through different operational modes, it conducts corresponding tests for various thermostatic valve configurations. The equipment features water pressure adjustment, flow measurement, and water temperature indication capabilities.

Technical Specifications
Test Functions Thermostatic valve performance test, faucet outlet sensitivity test
Hot and Cold Water Units 1 set 2000L
Temperature Range -5~90℃ (configurable)
Temperature Detection Inlet and outlet
Operation Mode Computerized
Operating Time 99H59M59S
Power Supply 380V/50HZ
Material SUS304 stainless steel
Flow Rate Maximum 50L/min/pressure 0-8kg
Water Pressure Regulation Automatic adjustment
Water Pressure Range 0.1--0.8MPa
Temperature Measurement Outlet temperature measurement using J-type thermocouple
System Components

Water Cooler:

  • Air-cooled chiller for refrigeration
  • Cold water tank uses electrode type water level switch for monitoring
  • Temperature range: 5℃-RT

Hot Water Tank:

  • Stainless steel heating tube for heating
  • Hot water tank uses electrode type water level switch for monitoring
  • Temperature range: RT-85℃
Compliance Standards

ASSE1016-2017, EN1111-2017

Company Profile
Sanitary Tapware Thermostatic Valve Performance Test Machine Valve Performance Tester
Our Partners
Sanitary Tapware Thermostatic Valve Performance Test Machine Valve Performance Tester
Our Service Advantages

Technical Support:

  • 48-hour response time for technical problems
  • Solutions provided within 3 working days
  • Operation videos and English manuals available
  • Video conference support

Onsite Services:

  • Device installation
  • Equipment operation and test technology training
  • Equipment calibration
  • Daily maintenance and equipment upkeep
  • Free technical training for factory visits
  • 24-hour online contact
  • Free software upgrades

Documentation Provided:

  • Product instructions
  • Product operation instructions/videos
  • Experiment test applications and reports

Problem Resolution:

  • 24-hour social media communication
  • Seamless email support
  • Video conferencing
  • Free on-site technical service
