Single Workstation Sanitary Hose 1000-Hour Continuous Pressure Tester
Single Workstation Sanitary Hose 1000-Hour Continuous Pressure Tester
Single Workstation Sanitary Hose 1000-Hour Continuous Pressure Tester
Single Workstation Sanitary Hose 1000-Hour Continuous Pressure Tester
Single Workstation Sanitary Hose 1000-Hour Continuous Pressure Tester
Single Workstation Sanitary Hose 1000-Hour Continuous Pressure Tester
Single Workstation Sanitary Hose 1000-Hour Continuous Pressure Tester
Single Workstation Sanitary Hose 1000-Hour Continuous Pressure Tester
Specifications
Type :
Testing Machine
Weight :
Approx. 120 kg
Protection Class :
/
Brand Name :
HAIDA
customized support :
OEM, ODM
Application :
Tissue Paper Test
Timer Range :
0-99.99 (Hours, Minutes, seconds)
Dimensions :
1000x1000x1600 mm
Place of Origin :
Guangdong, China
power :
220V 50HZ
Logo/graphic design :
Hot Stamping, Screen Printing
Vacuum Generation :
Vacuum pump
MOQ :
1
Voltage :
220V Electrical Equipment
Number of Workstations :
Single workstation
Pressure Adjustment :
Manual control
warranty :
1 Year
Observation Tube ID :
13 mm
Test Pressure :
0 ~0.1 PA (adjustable), 0.5% full scale accuracy
Immersion Depth :
13 mm
Test Fixtures :
Customized per specification (≥2 pcs each)
Description
Sanitary Hose 1000-Hour Continuous Pressure Tester
Product Overview

The Sanitary Hose 1000-Hour Continuous Pressure Tester is designed according to DS125 standards to conduct comprehensive simulation testing on sanitary hose products. The equipment fully immerses test specimens in a heated water tank while maintaining precise pressure control up to 500 PSI.

Single Workstation Sanitary Hose 1000-Hour Continuous Pressure Tester Single Workstation Sanitary Hose 1000-Hour Continuous Pressure Tester
Technical Specifications
Test Specimens 6 pcs (12 outlets or water outlets)
Water Tank Temperature Room Temperature - 90°C (Settable)
Water Temperature Displayable
Water Tank Dimensions Approx. 1300 × 1000 mm (W × D)
Air Pump 0-3.5 MPa (Usable with air or water pressure)
Sample Interface Customized according to product design
Control System PLC Software
Operation Interface 7" Color Touch Screen
Power Supply 380V/50HZ
Air Source ≥6 kg/cm²
Material SUS304 Stainless Steel
Company Profile
Single Workstation Sanitary Hose 1000-Hour Continuous Pressure Tester Single Workstation Sanitary Hose 1000-Hour Continuous Pressure Tester
Our Partners
Single Workstation Sanitary Hose 1000-Hour Continuous Pressure Tester Single Workstation Sanitary Hose 1000-Hour Continuous Pressure Tester
Our Service Advantages
Technical Support
  • 48-hour response guarantee for any testing process problems
  • Solution provision within 3 working days
  • Operation videos and English operation manuals available
  • Video conference support
Onsite Services
  • Device installation and setup
  • Equipment operation test technology training
  • Equipment calibration services
  • Daily maintenance and equipment upkeep
  • Free technical training for visiting factories
  • 24-hour online contact support
  • Free software upgrades
Documentation & Resources
  • Product instruction manuals
  • Product operation instructions and videos
  • Experiment test applications and reports
Device Problem Resolution
  • Social media 24-hour online communication
  • Seamless email support
  • Video conferencing for technical issues
  • Free on-site technical service when required
