Specifications
Brand Name :
PR
Model Number :
PR 3101
Certification :
CO
Place of Origin :
Denmark
MOQ :
1
Price :
250-280usd
Payment Terms :
T/T
Supply Ability :
99pcs 4-6 weeks
Delivery Time :
5-7 work days
Operating Voltage Range :
4.5 V DC ... 32 V DC
Ingress Protection :
IP65
User Memory :
48 MB
Housing Material :
Stainless Steel
Model :
VE4050S2K1C1
Generic Code :
SICK8
Electrical Connection :
Screw Terminals
Packing :
New and origin with factory seal
Resolution :
12 bit x 12 bit
Tariff Code :
85365080
Range :
-200℃-1200℃
Relative Humidity :
5 to 95%, non-condensing
Coo :
Yes
Response Time :
≤1 second
Primary Power :
DC input, 2-wire
Description
TC Converter
PR 3101
  • Excellent accuracy, better than 0.1% of span
  • Excellent EMC performance and 50/60 Hz noise suppression
  • Selectable < 30 ms / 300 ms response time
  • Pre-calibrated temperature range
Environmental Conditions
Operating temperature-25°C to +70°C
Storage temperature-40°C to +85°C
Calibration temperature20...28°C
Relative humidity< 95% RH (non-cond.)
Protection degreeIP20
Installation inPollution degree 2 & meas. / overvoltage cat. II
Mechanical Specifications
Dimensions (HxWxD)113 x 6.1 x 115 mm
Weight approx.70 g
DIN rail typeDIN EN 60715/35 mm
Wire size0.13...2.5 mm² / AWG 26...12 stranded wire
Screw terminal torque0.5 Nm
VibrationIEC 60068-2-6
2...25 Hz±1.6 mm
25...100 Hz±4 g
Common Specifications
Supply
Supply voltage16.8...31.2 VDC
Max. required power0.52 W
Max. power dissipation0.52 W
Response Time
Response time (0...90%, 100...10%)< 30 ms / 300 ms (selectable)
Signal / noise ratioMin. 60 dB
ProgrammingDIP switches
Signal dynamics, input23 bit
Signal dynamics, output18 bit
AccuracyBetter than 0.1% of sel. range
EMC immunity influence< ±0.5% of span
Extended EMC immunity: NAMUR NE21, A criterion, burst< ±1% of span
Incorrect DIP-switch setting identification0 V / 0 mA output; LED 0.5 s / 1 Hz
Input Specifications
TC Input
Temperature range, TC J-100...+1200°C
Temperature range, TC K-180...+1372°C
Min. measurement range (span) - TC J & K50°C
Accuracy: the greater ofBetter than 0.1% of span or 1°C
Temperature coefficient: the greater of0.1°C/°C or ≤ ±0.01%/°C
Sensor cable resistance< 5 kΩ per wire
Cold junction compensation (CJC): Accuracy @ internal CJCBetter than ±2.5°C
Internal CJC error detectionYes
Open Thermocouple detectionYes - selectable via DIP-switch
Output Specifications
Common Output Specifications
Updating time10 ms
Current Output
Signal range0...23 mA
Programmable signal ranges0 / 4...20 mA
Sensor error indication (0...20 mA)0 mA or 23 mA / OFF
Sensor error indication (4...20 mA)3.5 mA or 23 mA / acc. to NAMUR NE43 or OFF
Load (@ current output)≤ 600 Ω
Load stability≤ 0.01% of span / 100 Ω
Current limitation @ low output load< 60 mA peak / < 4 mA average
Voltage Output
Programmable signal ranges0/1...5 and 0/2...10 V
Sensor error indication0 V / 10% above the max. / none
Load (@ voltage output)≥ 10 kΩ
Open output< 18 V
I.S. / Ex Marking
ATEXII 3 G Ex ec IIC T4 Gc
IECExEx ec IIC T4 Gc
FM, USCl. I, Div. 2, Gp. A, B, C, D T4 or Cl. I, Zone 2, AEx nA IIC T4
FM, CACl. I, Div. 2, Gp. A, B, C, D T4 or Cl. I, Zone 2, Ex nA IIC T4
EAC Ex2Ex nA IIC T4 Gc X
Observed Authority Requirements
EMC2014/30/EU & UK SI 2016/1091
LVD2014/35/EU & UK SI 2016/1101
ATEX2014/34/EU & UK SI 2016/1107
RoHS2011/65/EU & UK SI 2012/3032
EACTR-CU 020/2011
EAC ExTR-CU 012/2011
Approvals
ATEXKEMA 10ATEX0147 X
IECExKEM 10.0068X
UKEXDEKRA 21UKEX0055X
c FM usFM17US0004X / FM17CA0003X
c UL us, UL 61010-1E314307
EAC ExEAEU KZ 7500361.01.01.08756
DNV MarineTAA00001RW
