Specifications
Delivery Time :
2-8 work days
Model Number :
ONV-IPS33168PFM-4GF
Packaging Details :
Packaging dimensions: 250*205*87mm, weight: 1.3kg, Carton dimensions: 520*430*360mm, 16 pcs/carton, weight: 22kg
Operating temperature :
-40~+80°C
Forwarding rate :
23.81Mpps
Input voltage :
DC44-57V
Max PoE power :
30W per port
Payment Terms :
T/T
Supply Ability :
500000pcs/month
Switching capacity :
52Gbps
Place of Origin :
China
MOQ :
1
PoE ports :
8 (Ports 1-8)
Brand Name :
ONV
Certification :
CE, FCC, RoHS
Description
16-port Gigabit Managed Industrial PoE Switch
Product Overview

The ONV-IPS33168PFM-4GF is a Gigabit L2+ managed industrial PoE fiber switch independently developed by ONV. It features 12×10/100/1000Base-T auto-sensing RJ45 ports and 4×100/1000Base-X SFP fiber ports. Ports 1-8 support the IEEE 802.3af/at PoE standard with single-port PoE power up to 30W.

As a PoE power supply device, it automatically detects and identifies compliant powered devices and supplies power via the network cable. It can power PoE terminal devices such as wireless APs, network cameras, VoIP phones, and industrial sensors, meeting the needs of network environments requiring high-density PoE power supply.

Ideal for building economical, efficient, stable, and reliable communication networks in industrial scenarios including intelligent transportation, rail transit, power industry, mining, oil, shipping, metallurgy, and green energy construction.

The ONV-IPS33168PFM-4GF features L2+ network management capabilities, supports IPv4/IPv6 management, static route forwarding, and comprehensive security protection mechanisms. It offers robust ACL/QoS policies and rich VLAN functionality for easy management and maintenance.

Technical Specifications
Model

ONV-IPS33168PFM-4GF

Interface Characteristics
Fixed Port Power-off alarm switch (FAULT) 1×Console RS232 port (115200, N,8,1) 8×10/100/1000Base-T PoE ports (Data/Power) 4×10/100/1000Base-T uplink RJ45 ports (Data) 4×100/1000Base-X uplink SFP fiber ports (Data) 2 set V+, V- redundant DC power port (6P industrial Phoenix terminal)
Ethernet Port Ports 1-12 support 10/100/1000Base-T auto-sensing, full/half duplex MDI/MDI-X self-adaption
Twisted Pair Transmission 10BASE-T: Cat3,4,5 UTP (≤100 meters)
100BASE-TX: Cat5 or later UTP (≤100 meters)
1000BASE-T: Cat5e or later UTP (≤100 meters)
Optical Fiber Port Gigabit SFP fiber port; does not include optical module (optional single-mode/multi-mode, single fiber/dual fiber optical module, LC)
Optical Fiber Port Expansion Support Turbo overclocking 2.5G optical module expansion and ring network
Optical Cable/Distance Multi-mode: 850nm/0-550m
Single-mode: 1310nm/0-40km, 1550nm/0-120km
Chip Parameters
Network Management Type L2+
Forwarding Mode Store and forward (Full wire speed)
Switching Capacity 52Gbps (non-blocking)
Forwarding Rate@64byte 23.81Mpps
CPU 416M
DRAM 1G
FLASH 128M
MAC 8K
Buffer Memory 4M
Jumbo Frame 9.6K
PoE & Power Supply
PoE Port Port 1-8
Max Power Per Port 30W, IEEE 802.3af/at
Power Consumption Standby<10W, full load<120W, at<240W
Input Voltage/Interface DC44-57V, 6P industrial Phoenix terminal supports anti-reverse protection
Physical Parameters
Operation Temp/Humidity -40~+80°C, 5%~90% RH non-condensing
Storage Temp/Humidity -40~+85°C, 5%~95% RH non-condensing
Dimension (L×W×H) 165×148×54mm
Net/Gross Weight 1.1kg/1.3kg
Installation Desktop, 35mm DIN Rail
Product Features
Gigabit Access, SFP Port Uplink
  • Supports non-blocking line-speed forwarding for smoother transmission
  • Supports IEEE 802.3x full-duplex flow control and backpressure half-duplex flow control
  • Supports combinations of Gigabit RJ45 ports and optical ports for flexible network configuration
Smart PoE Power Supply
  • PoE ports support priority mechanism for optimal power distribution
  • Compliant with IEEE 802.3af/at PoE standard, automatically identifying PoE devices
  • 8×10/100/1000Base-T RJ45 ports support PoE power supply
  • Comprehensive PoE network management functions including power allocation and scheduling
Strong Business Processing Ability
  • Support ERPS ring network and STP/RSTP/MSTP for link backup
  • Support IEEE802.1Q VLAN with flexible VLAN division
  • Support static and dynamic aggregation for load balancing
  • Comprehensive QoS and ACL support for security access control
Enhanced Security
  • Port isolation and storm control
  • IP+MAC+port+VLAN quadruple flexible combination binding
  • 802.1X authentication for LAN computers
Stable and Reliable Operation
  • CE, FCC, RoHS certified
  • User-friendly panel with comprehensive LED indicators
  • Low power consumption with aluminum alloy housing for excellent heat dissipation
Easy Operation & Maintenance
  • CPU monitoring, memory monitoring, Ping detection, and cable detection
  • Secure management via HTTPS, SSLV3, SSH V1/V2
  • RMON, system logs, and port traffic statistics for network optimization
  • Multiple management methods: Web, CLI, SNMP
Product Dimensions
16-port Gigabit Managed Industrial PoE Switch with 30W per Port and 52Gbps Switching Capacity
Application Diagram
16-port Gigabit Managed Industrial PoE Switch with 30W per Port and 52Gbps Switching Capacity
Ordering Information
Model Description Recommended Power Supply
ONV-IPS33168PFM-4GF L2+ managed industrial PoE switch with 12×10/100/1000M RJ45 ports and 4×100/1000M uplink SFP fiber ports. Ports 1-8 support the IEEE 802.3af/at PoE standard. Supports dual DC redundant power input and DIN rail mounting. 120W/240W

Note: The optical module and power supply are not included and need to be purchased separately.

Packing List
Item Qty Unit
16-port Gigabit managed industrial PoE switch 1 PC
RJ45-DB9 Adapter Cable 1 PC
User Guide 1 PC
Warranty Card and Certificate of Conformity 1 PC
Related Products
Model Description
ONV-IPS33064PFM L2+ managed industrial PoE switch with 4×10/100/1000M RJ45 ports and 2×100/1000M uplink SFP fiber ports
ONV-IPS33084PFM L2+ managed industrial PoE switch with 4×10/100/1000M RJ45 ports and 4×100/1000M uplink SFP fiber ports
ONV-IPS33108PFM L2+ managed industrial PoE switch with 8×10/100/1000M RJ45 ports and 2×100/1000M SFP fiber ports
ONV-IPS33148PFM L2+ managed industrial PoE switch with 10×10/100/1000M RJ45 ports and 4×100/1000M uplink SFP fiber ports
ONV-IPS33168PFM L2+ managed industrial PoE switch with 8×10/100/1000M RJ45 ports and 8×100/1000M uplink SFP fiber ports
