ANSI 52-1 Ceramic Suspension Disc Insulator 11kV With Ball And Socket Type End Fitting
ANSI 52-1 Ceramic Suspension Disc Insulator 11kV With Ball And Socket Type End Fitting
Specifications
Brand Name :
MacweyTEK
Model Number :
FXBW
Certification :
IEC
Place of Origin :
China
MOQ :
1 piece
Price :
$5
Payment Terms :
T/T
Supply Ability :
20000
Delivery Time :
10 days
Packaging Details :
cartons
Name :
ANSI 52-1
Rated Voltage :
11kV
Structure & Material :
Ball and Socket End Fitting, Hydrophobic Silicone Rubber + FRP Core
Mechanical Strength :
70kN/100kN
Application :
Overhead Distribution Lines (Suspension/Tension)
Core Feature :
Pollution Flashover Resistant, Water-Repellent
Description

ANSI 52-1 for high voltage Ceramic Suspension Disc Insulators 11kv 70KN Overhead Line Insulators

11kV Polymer Disc Insulator is specially engineered for 11kV overhead distribution lines, offering a reliable solution for both suspension and tension applications. This product adopts a ball and socket type end fitting design, ensuring secure and standardized connections in power line systems.

Made from high-quality hydrophobic silicone rubber, the 11kV polymer disc insulator demonstrates excellent performance in resisting pollution flashover and maintaining electrical insulation under harsh environmental conditions. The inherent water-repellent (hydrophobic) properties of the silicone housing help prevent the formation of conductive water films, significantly improving the long-term reliability of the insulator.

For mechanical strength, two options are available: 70kN and 100kN, depending on your project’s load requirements. Both options use a high-strength fiber-reinforced epoxy core (FRP rod), providing excellent tensile resistance and structural stability.

The 11kV polymer disc insulator price offered by Gaoya Power starts at USD 2.5 per piece (EXW), subject to change based on design parameters and material selection.

11 kV Polymer Disc Insulator Technical Drawing and Specifications

ANSI 52-1 Ceramic Suspension Disc Insulator 11kV With Ball And Socket Type End Fitting

Model Rated Voltage (kV) Specified Mechanical Load (kN) Section Length (mm) Arcing Distance (mm) Creepage Distance (mm) Coupling Size Lightning Impulse Withstand Voltage (kV) Power Frequency Withstand Voltage (kV), dry Power Frequency Withstand Voltage (kV), wet
FXBW-11/70 11 70 266 150 305 16 95 55 50
FXBW-11/100 11 100 290 220 450 16 145 80 70
