Specifications
product_name :
NCM51Ah Standard Module
module_type :
Standard Module
composition :
1P12S NCM51Ah, data collecting unit of BMS and fixed fittings
capacity :
51Ah
voltage :
43.44V
group_structure :
Standard group structure
series_connection :
expand voltage
parallel_connection :
expand capacity
Description

Product Description


No. Items STANDARD MODULE Note
NCM51AH1P12S
1 Nominal voltage(V) 43.44
2 Operating voltage(V) min 33.6 T＞5℃
3 max 50.4
4 Nominal capacity(Ah) 51 25℃,1/3C,100%DOD
5 Nominal energy(KWh ) 2.215 25℃,1/3C,100%DOD
7 Group mode 1P12S
8 Module weight(kg) 11.5
9 Maximum continuous charge current(A) 51
10 Maximum continuous discharge current(A) 153
11 Maximum pulse discharge current(≤10s)(A) 416 30s
12 SOC operating range(%) 15-95
13 Module cooling method Natural cooling
14 Module heating method NO
15 Shipping capacity (SOC) ≈30% SOC is consistency in the same batch
16 Dimension L (mm) 355
Dimension W (mm) 151.5
Dimension H (mm) 108

NCM51AH 1P12S VDA Module Dimensions


DRAWING INTERFACE TYPE



01 02

Carton for air transportation and Meeting the UN38.3 package
plywood case for sea transportation standard for dangerous goods
