Specifications
Brand Name :
OiD
Model Number :
OID9590190-30000-25.2V
Certification :
UN38.3, MSDS
Place of Origin :
China
MOQ :
1pcs
Price :
$0.5 ~ $200.0 / pcs
Payment Terms :
TT,L/C,Western Union
Supply Ability :
1000000
Delivery Time :
3 ~ 30 days for storage
Packaging Details :
Carton
Name :
Drone Lipo Battery
ODM :
Free custom design for packs
Capacity :
30000mAh
Battery Type :
25.2V 30000mAh Rechargeable
Cycle Life :
300+ cycles
Charging/ Discharging :
30A/300A
Operating Temperature :
-10°C to +60°C
Compatibility :
XT90/XH2.54-7P connector
Weight/ size :
2352g/95.5 × 76.5 × 205.0 mm
Description
25.2V 30000mAh Semi-Solid-State Drone Battery with 5C High Discharge for UAV Applications
The OID9590190-30000-25.2V Semi-Solid-State Drone Battery Pack is a high-energy lithium-ion battery designed for professional UAV systems and high-power drone applications. With approximately 320Wh/kg energy density, 5C continuous discharge capability, and 10C burst current, this battery delivers reliable power output for industrial drones requiring stable high-current performance.

Key Features
  • Semi-Solid-State Lithium Technology: Higher energy density compared with conventional lithium batteries, enabling longer flight endurance
  • High Power Output: Supports 150A continuous discharge (5C) and 300A burst discharge (10C) for high-power UAV motors
  • High Energy Density: Approximately 320Wh/kg, improving endurance and reducing UAV payload weight
  • Reliable Safety Performance: Tested for vibration, drop, short circuit, overcharge, and forced discharge to ensure operational safety
  • Industrial Grade Stability: Designed to operate under wide temperature ranges for demanding drone environments

Technical Specifications
Product Model OID9590190-30000-25.2V
Battery Type Semi-Solid-State Lithium-Ion
Nominal Capacity 30000mAh
Typical Capacity 30200mAh
Minimum Capacity 29700mAh
Nominal Voltage 25.2V
Cell Configuration 7S (7 cells in series)
Charge Cut-off Voltage 29.4V
Discharge Cut-off Voltage 17.5V
Standard Charge Current 15A (0.5C)
Maximum Charge Current 30A (1C)
Standard Discharge Current 15A (0.5C)
Maximum Continuous Discharge 150A (5C)
Maximum Burst Discharge 300A (10C ≤2s)
Internal Impedance ≤10.1mΩ
Energy Density ~320Wh/kg
Weight 2352g ±2.5%
Dimensions Max 95.5 × 76.5 × 205.0 mm
Charging Temperature 10°C ~ 45°C
Discharging Temperature -10°C ~ 60°C

Performance Characteristics
High-Rate Discharge Performance
The battery maintains ≥ 90% of minimum capacity under 5C discharge, ensuring stable power output during demanding UAV operations.
Temperature Performance
Temperature Capacity Retention
-10°C ≥60%
25°C ≥100%
60°C ≥95%
Cycle Life
Under 1C charge / 3C discharge cycling conditions, the battery maintains ≥ 80% capacity after 300 cycles.

Storage Performance
Storage Condition Performance
28 days at 23°C ≥85% remaining capacity
7 days at 60°C ≥60% remaining capacity
1 year storage ≥85% recovery capacity
Recommended long-term storage:
  • Temperature: 25 ±3°C
  • Humidity: ≤ 75% RH
  • Recharge every 3 months

Safety Tests
The battery pack has passed multiple industrial safety tests:
  • Vibration test (10-55Hz sweep)
  • 1 meter drop test
  • Short circuit protection test
  • Overcharge test (3C to 32.2V)
  • Forced discharge test
All tests confirmed: No fire, no explosion, no leakage.

Applications
  • Industrial inspection drones
  • Agricultural spraying UAVs
  • Surveying and mapping drones
  • Logistics and delivery drones
  • Security and surveillance UAVs

Safety Guidelines
To ensure safe operation:
  • Do not short circuit battery terminals
  • Do not disassemble or puncture the battery pack
  • Use only specified chargers
  • Do not expose to fire or extreme heat
  • Do not immerse in water
  • Stop using immediately if deformation, overheating, or unusual odor occurs
Improper handling may cause fire, explosion, or leakage.

Warranty
The warranty period is 6 months from the date of shipment. Shenzhen Jianheng Technology Co Ltd will replace defective battery packs free of charge if failure is caused by material or manufacturing defects under proper operating conditions.
