22.2V 27000mAh Drone Battery 100A Peak Discharge 200 Cycles
22.2V 27000mAh Drone Battery 100A Peak Discharge 200 Cycles
22.2V 27000mAh Drone Battery 100A Peak Discharge 200 Cycles
22.2V 27000mAh Drone Battery 100A Peak Discharge 200 Cycles
Specifications
Brand Name :
OiD
Model Number :
OiDA988188-27000-5C-22.2
Certification :
Complies with GB31241-2014/GB/T 18287-2013 (China National Standard).
Place of Origin :
China
MOQ :
100pcs
Price :
$0.5 ~ $100.0 / pcs
Delivery Time :
3 ~ 7 days for storage
Payment Terms :
TT,L/C,Western Union
Name :
27000 mAh Battery
Battery Type :
22.2V 27000mAh Rechargeable
ODM :
Free custom design for packs
Cycle Life :
200+ cycles
Charging/ Discharging :
13.5A/60A
Operating Temperature :
-20°C~60°C
Compatibility :
XT90S-F (discharge), JST-XHR-7P (charge)
Weight/ size :
2340g/20x 91.5 x 61mm
Description

OiDA988188-27000-5C-22.2 Drone Battery 22.2V 27000mAh 100A Peak Discharge 200 Cycles

Product Name

OiDA988188-27000-5C-22.2 Drone Battery

Advantages

  • Ultra-high capacity for extended flight endurance
  • Optimized 5C discharge rate for stable power output
  • Lightweight design with robust cycle life

Specifications

Parameter

Value

Nominal Voltage

22.2V (6S1P)

Nominal Capacity

27000mAh (0.5C discharge)

Minimum Capacity

25770mAh

Internal Impedance

8.36±1.5mΩ (1kHz AC method)

Charging

Standard Charge Current

5.4A (0.2C)

Fast Charge Current

13.5A (0.5C)

Max Charge Voltage

25.2V

Discharging

Standard Discharge Current

5.4A (0.2C)

Max Continuous Discharge

60A (2.2C)

Peak Discharge Current

100A (≤3 seconds)

Discharge Cut-Off Voltage

17.1V (0.2C) / 18.0V (≥0.5C)

Dimensions

207±2.5mm (L) x 91.5±1.5mm (W) x 61±1.5mm (H)

Weight

2340±100g

Connectors

XT90S-F (discharge), JST-XHR-7P (charge)

Cycle Life

Test Condition

Cycles

0.5C CC/CV charge to 25.2V, 60A discharge to 18.0V (Capacity ≥80% of initial)

200

Operating Temperature Range

Operation

Temperature Range

Current Limit

Charging

10°C to 45°C

≤13.5A (0.5C)

Discharging

-20°C to 60°C

≤60A (10°C–45°C recommended)

Storage

-10°C to 45°C

N/A

Certifications

Complies with GB31241-2014/GB/T 18287-2013 (China National Standard).

Key Features

  • Fast Charging: Supports 0.5C charging (3 hours).
  • High Efficiency: ≥98% discharge efficiency at 20°C.
  • Durable Design: Aluminum foil packaging with impact resistance.

Applications

  • Heavy-lift industrial drones
  • Long-range aerial mapping
  • High-power FPV racing drones
  • 22.2V 27000mAh Drone Battery 100A Peak Discharge 200 Cycles

Usage Warnings & Precautions

  • Voltage Limits: Do not exceed 25.2V (charge) or discharge below 17.1V (0.2C).
  • Temperature: Avoid charging below 10°C or discharging above 60°C.
  • Safety: Never disassemble or expose to water/fire.

Storage Guidelines

  • Short-term: Store at 21.6–23.4V (23±5°C, 65±20% RH).
  • Long-term: Maintain 21.6–23.4V; activate every 3 months (0.2C cycle).

Warranty & Disclaimer

  • 12-month warranty from shipment date.
  • Void if misused or stored improperly.
