44.4V 30000mAh Drone Lipo Battery 150A Peak Discharge
44.4V 30000mAh Drone Lipo Battery 150A Peak Discharge
44.4V 30000mAh Drone Lipo Battery 150A Peak Discharge
44.4V 30000mAh Drone Lipo Battery 150A Peak Discharge
Specifications
Brand Name :
OiD
Model Number :
OiDA988188-30000-5C-44.4
Certification :
Complies with GB31241-2014/GB/T 18287-2013 safety standards.
Place of Origin :
China
MOQ :
100pcs
Price :
$0.5 ~ $100.0 / pcs
Delivery Time :
3 ~ 7 days for storage
Payment Terms :
TT,L/C,Western Union
Name :
Drone Lipo Battery
ODM :
Free custom design for packs
Battery Type :
44.4V 30000mAh Rechargeable
Cycle Life :
300+ cycles
Charging/ Discharging :
30A/90A
Operating Temperature :
-20°C~60°C
Compatibility :
AS150U-F (Discharge), Molex-430451600 (Balance)
Weight/ size :
5400g/207×90.5×132mm
Description

OiDA988188-30000-5C-44.4 Drone Battery 44.4V 30000mAh 150A Peak Discharge 300 Cycles

Product Name

High-Performance 12S1P 44.4V 30000mAh Lithium Polymer Drone Battery

Advantages

  • Ultra-high capacity for extended flight endurance.
  • High-rate 5C discharge capability for demanding applications.
  • Optimized weight-to-power ratio for industrial drone use.

Specifications

No.

Item

Specification

1

Configuration

12S1P (12 Series, 1 Parallel)

2

Nominal Voltage

44.4V (Cell: 3.7V)

3

Nominal Capacity

30000mAh @ 0.5C Discharge

4

Minimum Capacity

29300mAh @ 0.5C Discharge

5

Open-Circuit Voltage

50.4V (Cell: 4.2V)

6

Max Charge Current

30A (1C) to 50.4V, CV until ≤0.02C

7

Max Continuous Discharge

90A (3C) to 34.2V

8

Peak Discharge Current

150A (5C, ≤3s)

9

Internal Impedance

15.0±4.5mΩ

10

Dimensions (L×W×H)

207×90.5×132mm (Max)

11

Weight

5400±200g

12

Terminals

AS150U-F (Discharge), Molex-430451600 (Balance)

Cycle Life

Test Condition

Performance

1. Charge: 15A to 50.4V, end current ≤0.02C

2. Rest: 10min

3. Discharge: 90A to 34.2V

≥300 cycles (80% capacity retention)

4. Rest: 30min

5. Repeat steps 1–4 until capacity <80%

Discharge Curve

  • 90A Discharge: ~18 minutes to 34.2V after standard charge.
  • Low-Temp Performance: ≥70% capacity at -20°C (0.2C discharge).

Operating Temperature Range

Scenario

Temperature Range

Current/Power Limit

Charging

10°C–45°C

≤30A (1C)

Discharging

-20°C–60°C

-20°C–0°C: ≤0.2C

0°C–60°C: ≤90A (3C)

Storage (Short-term)

-20°C–35°C (≤7 days at >46.8V)

N/A

Storage (Long-term)

-20°C–35°C (45.0V–46.8V)

Activate every 3 months

Certifications

  • Complies with GB31241-2014/GB/T 18287-2013 safety standards.

Key Features

  • Fast Charging: Fully charges in 1.5 hours (30A) or 3 hours (15A).
  • High-Temp Stability: 95% capacity recovery after 60°C storage.
  • Low Self-Discharge: ≤15% capacity loss after 28 days at 25°C.

Applications

  • Heavy-lift industrial drones, long-endurance UAVs, and aerial mapping systems.

Usage Warnings44.4V 30000mAh Drone Lipo Battery 150A Peak Discharge & Precautions

  • Charging: Use CC/CV chargers (max 50.4V). Reverse polarity prohibited.
  • Discharging: Avoid >150A currents or temperatures <-20°C/＞60°C.
  • Physical Handling: Protect aluminum casing from sharp objects.

Storage Guidelines

  • Short-term: Store at 45.0V–46.8V (25°C).
  • Long-term: Maintain 45.0V–46.8V; activate every 3 months (0.2C cycle).

Warranty & Disclaimer

  • 12-month warranty from shipment date. Void if misused (overcharge, puncture, etc.).
  • Not liable for accidents caused by improper operation.
