Mitsubishi AA084SD11 Industrial TFT Monitor Screen High Brightness 1200nits Display
Mitsubishi AA084SD11 Industrial TFT Monitor Screen High Brightness 1200nits Display
Mitsubishi AA084SD11 Industrial TFT Monitor Screen High Brightness 1200nits Display
Mitsubishi AA084SD11 Industrial TFT Monitor Screen High Brightness 1200nits Display
Mitsubishi AA084SD11 Industrial TFT Monitor Screen High Brightness 1200nits Display
Mitsubishi AA084SD11 Industrial TFT Monitor Screen High Brightness 1200nits Display
Mitsubishi AA084SD11 Industrial TFT Monitor Screen High Brightness 1200nits Display
Mitsubishi AA084SD11 Industrial TFT Monitor Screen High Brightness 1200nits Display
Mitsubishi AA084SD11 Industrial TFT Monitor Screen High Brightness 1200nits Display
Mitsubishi AA084SD11 Industrial TFT Monitor Screen High Brightness 1200nits Display
Mitsubishi AA084SD11 Industrial TFT Monitor Screen High Brightness 1200nits Display
Mitsubishi AA084SD11 Industrial TFT Monitor Screen High Brightness 1200nits Display
Specifications
Delivery Time :
1-3 working days
Power Supply :
3.3V (Typ.)
Supplier Type :
Original Brand
Type :
TFT
Payment Terms :
L/C,D/A,D/P,T/T,
Place of Origin :
Japan
Brand Name :
Mitsubishi
Price :
$358/pieces 1-99 pieces
Viewing Angle :
80/80/80/60 (Typ.)(CR 10)
Frame Rate :
60Hz
Touch panel :
Withtout
Application :
Industrial Equipment
MOQ :
1
Display Size :
8.4inch
Brightness :
1200cd/m2
Panel Type :
a-Si TFT-LCD, LCM
Interface :
LVDS
Model Number :
AA084SD11
Resolution :
800x600
Module Outsize(mm) :
199.5(H)x149(V) x10.2(D) mm
Description
Mitsubishi 8.4-inch Industrial TFT Display
High-performance 800×600 SVGA resolution TFT-LCD display module with LVDS interface, wide temperature range, and ultra-high brightness of 1200 nits.
Key Features
  • SVGA 800×600 resolution at 119 PPI
  • Ultra-high brightness: 1200 cd/m²
  • Wide operating temperature: -30°C to 80°C
  • LVDS interface (1 ch, 6/8-bit)
  • 600:1 contrast ratio
  • 262K/16.7M color support
  • Long-life WLED backlight (100K hours)
Technical Specifications
Panel Model AA084SD11
Panel Brand Mitsubishi
Size 8.4 inch
Panel Type a-Si TFT-LCD, LCM
Resolution 800(RGB)×600, SVGA 119PPI
Module Dimensions 199.5(W)×149(H)×10.2(D) mm
Active Area 170.4(W)×127.8(H) mm
Display Mode TN, Normally White, Transmissive
Response Time 4/12 ms (Typ.)(Tr/Td)
Viewing Angle 80/80/80/60 (Typ.)(CR≥10)
Brightness 1200 cd/m² (Typ.)
Contrast Ratio 600:1 (Typ.)
Power Supply 3.3V (Typ.)
Interface LVDS (1 ch, 6/8-bit), 20 pins Connector
Operating Temperature -30°C to 80°C
Storage Temperature -30°C to 80°C
Applications
Ideal for industrial equipment, control systems and other applications requiring reliable performance in demanding environments.
