Specifications
Type :
TFT
Display Size :
18.5 inch
Supplier Type :
Original Brand
Place of Origin :
China
Brand Name :
AUO
Panel Type :
a-Si TFT-LCD, LCM
Resolution :
1920(RGB)x1080, FHD 119PPI
Module Outsize(mm) :
430.4(W)x254.6(H) x12.5(D) mm
Viewing Angle :
89/89/89/89 (Typ.)(CR≥10)
Brightness :
350cd/m2
Interface :
LVDS (2 ch, 8-bit) , 30 pins Connector
Touch panel :
Withtout
Application :
Industrial Equipment Medical Imaging
MPQ :
8pcs
Warranty :
12 Months
Price :
$172/pieces 1-99 pieces
Description
Products Description
Panel Model
G185HAN01.0
Panel Brand
AUO
Size (inch )
18.5inch
Panel Type
a-Si TFT-LCD, LCM
Resolution
1920(RGB)×1080, FHD 119PPI
Pixel Format
RGB Vertical Stripe
Module Outsize(mm)
430.4(W)×254.6(H) ×12.5(D) mm
Display Mode
AHVA, Normally Black, Transmissive
LCD Active area(mm)
408.96(W)×230.04(H) mm
Response Time
10/10 (Typ.)(Tr/Td)
Display Colors
16.7M 99% sRGB
Light Source
9S7P WLED , 50K hours , With LED Driver
Viewing Angle
89/89/89/89 (Typ.)(CR≥10)
Touch Screen
Without
Brightness
350 cd/m² (Typ.)
Power Supply
5.0V (Typ.)
Contrast Ratio
1000:1 (Typ.) (TM)
Used for
Industrial, Medical Imaging
Frame Ratio
60Hz
Enviroment
Storage Temp.: -20 ~ 70 °C
Operating Temp.: -20 ~ 70°C
LCM Interface Type
LVDS (2 ch, 8-bit) , 30 pins Connector
FPC connector
JAE, FI-XB30SSRLA-HF16, Pitch 1.0mm
Details Images
AUO G185HAN01.0 18.5 Inch Industrial Screen Module 1920x1080 FHD AHVA sRGB LVDS Industrial Medical Imaging TFT-LCD Display
AUO G185HAN01.0 18.5 Inch Industrial Screen Module 1920x1080 FHD AHVA sRGB LVDS Industrial Medical Imaging TFT-LCD Display
AUO G185HAN01.0 18.5 Inch Industrial Screen Module 1920x1080 FHD AHVA sRGB LVDS Industrial Medical Imaging TFT-LCD Display
AUO G185HAN01.0 18.5 Inch Industrial Screen Module 1920x1080 FHD AHVA sRGB LVDS Industrial Medical Imaging TFT-LCD Display
AUO G185HAN01.0 18.5 Inch Industrial Screen Module 1920x1080 FHD AHVA sRGB LVDS Industrial Medical Imaging TFT-LCD Display
AUO G185HAN01.0 18.5 Inch Industrial Screen Module 1920x1080 FHD AHVA sRGB LVDS Industrial Medical Imaging TFT-LCD Display
Company Profile
AUO G185HAN01.0 18.5 Inch Industrial Screen Module 1920x1080 FHD AHVA sRGB LVDS Industrial Medical Imaging TFT-LCD Display
AUO G185HAN01.0 18.5 Inch Industrial Screen Module 1920x1080 FHD AHVA sRGB LVDS Industrial Medical Imaging TFT-LCD Display
AUO G185HAN01.0 18.5 Inch Industrial Screen Module 1920x1080 FHD AHVA sRGB LVDS Industrial Medical Imaging TFT-LCD Display
FAQ
Q1. What is your lead time? A: Stock: 5-15 days in general. No stock: 15-30 days after samples confirmed. Or please contact us by email for specific lead time base on your order quantities. Q2. How does your factory do regarding quality control? A: Quality is priority. We always attach great importance to quality control from the very beginning to the end: 1) All raw material we used are non-toxic, environmental-friendly; 2) Skillful workers pay great attention to each details in handling the producing and packing processes; 3) We have a professional QA/QC team to ensure the quality. Q3. Do you accept OEM or ODM order? A: Yes, we accept both OEM and ODM for customers. Q4. What are your terms of delivery? A: We can accept EXW, FOB, CIF, etc. You can choose one which is the most convenient for you. Q5. What is the payment way? A: TT, Pay Later, West Union,Online Bank Payment. Should you have other questions, please let us know. We’ll add answers here for your further references. Thank you.
