Specifications
Type :
TFT
Display Size :
37 inch
Supplier Type :
Original Brand
Place of Origin :
China
Brand Name :
Innolux
Panel Type :
a-Si TFT-LCD, LCM
Resolution :
1920(RGB)x540 53PPI
Module Outsize(mm) :
923.3(H)x277.1(V) x28.4(D) mm
Viewing Angle :
89/89/89/89 (Typ.)(CR≥10)
Brightness :
1000cd/m2
Interface :
LVDS (2 ch, 8-bit) , 51 pins Connector
Touch Screen :
Without
Application :
Industrial Equipment, Outdoor High Brightness, Digital Signage
MPQ :
10pcs
Warranty :
12 Months
Price :
$270/pieces 1-99 pieces
Description
Innolux 37-Inch TFT LCD Panel 1920x540 Resolution High Brightness 1000nits for Industrial Digital Signage Display Module
Products Description
Panel Model
S370AJ1-LE1
Panel Brand
Innolux
Size (inch )
37inch
Panel Type
a-Si TFT-LCD, LCM
Resolution
1920(RGB)×540 53PPI
Pixel Format
RGB Vertical Stripe
Module Outsize(mm)
923.3(W)×277.1(H)×28.4(D) mm
Display Mode
Super MVA, Normally Black, Transmissive
LCD Active area(mm)
904.32(W)×254.34(H) mm
Response Time
11 (Typ.)(G to G)
Display Colors
16.7M 72% NTSC
Light Source
WLED , 50K hours , With LED Driver
Viewing Angle
89/89/89/89 (Typ.)(CR≥10)
Touch Screen
Without
Brightness
1000 cd/m² (Typ.)
Power Supply
12V (Typ.)
Contrast Ratio
5000:1 (Typ.) (TM)
Used for
Industrial, Outdoor High brightness, Digital Signage, Advertising, Stretched Bar LCD
Frame Ratio
60Hz
Enviroment
Storage Temp.: -20~ 60 °C
Operating Temp.: -20 ~ 60 °C
LCM Interface Type
LVDS (1 ch, 6-bit) , Connector 20 pins
FPC connector
P-two, 187059-51221, Pitch 0.5mm
Innolux 37-Inch TFT LCD Panel 1920x540 Resolution High Brightness 1000nits for Industrial Digital Signage Display Module
Innolux 37-Inch TFT LCD Panel 1920x540 Resolution High Brightness 1000nits for Industrial Digital Signage Display Module
Innolux 37-Inch TFT LCD Panel 1920x540 Resolution High Brightness 1000nits for Industrial Digital Signage Display Module
Innolux 37-Inch TFT LCD Panel 1920x540 Resolution High Brightness 1000nits for Industrial Digital Signage Display Module
Innolux 37-Inch TFT LCD Panel 1920x540 Resolution High Brightness 1000nits for Industrial Digital Signage Display Module
Innolux 37-Inch TFT LCD Panel 1920x540 Resolution High Brightness 1000nits for Industrial Digital Signage Display Module
Innolux 37-Inch TFT LCD Panel 1920x540 Resolution High Brightness 1000nits for Industrial Digital Signage Display Module
Innolux 37-Inch TFT LCD Panel 1920x540 Resolution High Brightness 1000nits for Industrial Digital Signage Display Module
Innolux 37-Inch TFT LCD Panel 1920x540 Resolution High Brightness 1000nits for Industrial Digital Signage Display Module
Details Images
Company Profile
Innolux 37-Inch TFT LCD Panel 1920x540 Resolution High Brightness 1000nits for Industrial Digital Signage Display Module
Innolux 37-Inch TFT LCD Panel 1920x540 Resolution High Brightness 1000nits for Industrial Digital Signage Display Module
Innolux 37-Inch TFT LCD Panel 1920x540 Resolution High Brightness 1000nits for Industrial Digital Signage Display Module
Innolux 37-Inch TFT LCD Panel 1920x540 Resolution High Brightness 1000nits for Industrial Digital Signage Display Module
Innolux 37-Inch TFT LCD Panel 1920x540 Resolution High Brightness 1000nits for Industrial Digital Signage Display Module
Innolux 37-Inch TFT LCD Panel 1920x540 Resolution High Brightness 1000nits for Industrial Digital Signage Display Module
Innolux 37-Inch TFT LCD Panel 1920x540 Resolution High Brightness 1000nits for Industrial Digital Signage Display Module
FAQ
Q1. What is your lead time? A: Stock: 5-15 days in general. No stock: 15-30 days after samples confirmed. Or please contact us by email for specific lead time base on your order quantities. Q2. How does your factory do regarding quality control? A: Quality is priority. We always attach great importance to quality control from the very beginning to the end: 1) All raw material we used are non-toxic, environmental-friendly; 2) Skillful workers pay great attention to each details in handling the producing and packing processes; 3) We have a professional QA/QC team to ensure the quality. Q3. Do you accept OEM or ODM order? A: Yes, we accept both OEM and ODM for customers. Q4. What are your terms of delivery? A: We can accept EXW, FOB, CIF, etc. You can choose one which is the most convenient for you. Q5. What is the payment way? A: TT, Pay Later, West Union,Online Bank Payment. Should you have other questions, please let us know. We’ll add answers here for your further references. Thank you.
