10.1 inch 1920*1080 LCD modules COG-VLSZT115-01 lcd screen
10.1 inch 1920*1080 LCD modules COG-VLSZT115-01 lcd screen
10.1 inch 1920*1080 LCD modules COG-VLSZT115-01 lcd screen
10.1 inch 1920*1080 LCD modules COG-VLSZT115-01 lcd screen
Specifications
Brand Name :
BOE
Model Number :
COG-VLSZT115-01
Place of Origin :
China
MOQ :
2 pcs
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
100000 Unit/Units per Month
Delivery Time :
7 Days
Packaging Details :
Original packaging/conventional packaging box
Model Name :
COG-VLSZT115-01
Screen Size :
10.1"
Panel Type :
a-Si TFT-LCD, LCM
Resolution :
1920(RGB)×1080, FHD 218PPI
Pixel Format :
RGB Vertical Stripe
Active Area :
223.488(W)×125.712(H) mm
Outline Dim. :
237.69(W)×142.7(H) ×11.7(D) mm
Luminance :
1100 cd/m² (Typ.)
Contrast Ratio :
1000:1 (Typ.) (TM)
Designed For :
Rugged Industry ，Outdoor High Brightness， Automotive Display
Description

10.1 inch 1920*1080 LCD modules COG-VLSZT115-01 lcd screen

Product details :

Brand BOE
Model P/N COG-VLSZT115-01
Diagonal Size 10.1"
Panel Type a-Si TFT-LCD, LCM
Resolution 1920(RGB)×1080, FHD 218PPI
Pixel Format RGB Vertical Stripe
Active Area 223.488(W)×125.712(H) mm
Bezel Opening -
Outline Dim. 237.69(W)×142.7(H) ×11.7(D) mm
Treatment Hard coating
Luminance 1100 cd/m² (Typ.)
Contrast Ratio 1000:1 (Typ.) (TM)
View Direction Symmetry
Response Time 30 (Typ.)(Tr+Td)
Viewing Angle 85/85/30/30 (Typ.)(CR≥10)
Operating Mode ADS, Normally Black, Transmissive
Support Color 16.7M 85% NTSC
Light Source 8S4P WLED , 30K hours , Without Driver
Weight -
Designed For Rugged Industry ,Outdoor High Brightness, Automotive Display
Frame Rate 60Hz
Touch Panel Without
Interface Type LVDS (2 ch, 8-bit) , 50 pins Connector
Power Supply 3.3V (Typ.)
Environment Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C ; Vibration Level: 10.0G (98 m/s²)

Why Choose Us :

According to customers' various requests,


we can match all accessories which inclusive of driver board,


touch-screen, LED backlight & LVDS cables. TFT LCD,


LCD panel, LCD display,LCD screen, LCD monitor,


LCD module from 2.2 inch to 88 inch.


Quality promised, 100% original,fast delivery,

Shipping and Package :

10.1 inch 1920*1080 LCD modules COG-VLSZT115-01 lcd screen

1)All of our product will be testing before shipping . So you can be assured the quality of our products

2) All Panels are packed with new and firm carton, capable of long distance transportation.

3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT

4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.

transportation:

After your payment, we will prepare and send your goods within 1-5 days.
Most regions take 7-14 business days (2-3 weeks) to receive.

DHL spends about 3-7 days a week;

FEdex took about 1 week;

EMS took about 2-3 weeks;

Hong Kong China Post airmail takes about 2-3 weeks;

China Post airmail takes about 3 weeks;

FAQ:

Q: How to make payment of COG-VLSZT115-01 ?

A: We accept T/T , Paypal , western union .

Q: If I place order now,when will you ship the goods of COG-VLSZT115-01 ?

A: The order will be shipped within 2-3 working days after received your payment.

Q: Can You declare my order of COG-VLSZT115-01 to a lower price in commercial invoice for customs ?

A: Yes , we can . pls inform us before shipping .

Q: How long is the warranty ?

A: We offer 90 days warranty .
