High-Accuracy Walk-in Temperature and Humidity Test Chamber Compliant With IEC 60068-2-2 and Stainless Steel 304 Construction
High-Accuracy Walk-in Temperature and Humidity Test Chamber Compliant With IEC 60068-2-2 and Stainless Steel 304 Construction
High-Accuracy Walk-in Temperature and Humidity Test Chamber Compliant With IEC 60068-2-2 and Stainless Steel 304 Construction
High-Accuracy Walk-in Temperature and Humidity Test Chamber Compliant With IEC 60068-2-2 and Stainless Steel 304 Construction
High-Accuracy Walk-in Temperature and Humidity Test Chamber Compliant With IEC 60068-2-2 and Stainless Steel 304 Construction
High-Accuracy Walk-in Temperature and Humidity Test Chamber Compliant With IEC 60068-2-2 and Stainless Steel 304 Construction
Specifications
Certification :
CE,ISO
MOQ :
1 Unit
Price :
Negotiable
Brand Name :
YOUBI
Model Number :
UP-6195
Place of Origin :
CHINA
Payment Terms :
T/T,D/P,Western Union,Paypal,Money Gram
Supply Ability :
30 Unit/month
Delivery Time :
5-15 work days
Packaging Details :
Professional Export Wooden Box Packaging
Product name :
Walk-in temperatrue and Humidity Test Chamber
Temperature Range :
-60ºC to +150ºC
Humidity Range :
20% to 98% Rh
Internal Material :
Stainless Steel 304
Working Room Capacity :
8cubic Meter(Can Be Customization)
Custom Service :
OEM,ODM
Size Service :
Support Customer Customization
External Material :
Stainless Steel/Paint Spray
Description
UP-6195 Compliant With IEC 60068-2-2 High-Accuracy Walk-in Temperature and Humidity Test Chamber
Application:

The test chamber is suitable for large size or a large number of machine products, parts, materials for high temperature, low temperature, high low temperature cycle test, and humid heat test. It is mainly used to simulate the product under the combined conditions of climate temperature and humidity or under the changing conditions of ambient temperature and humidity to detect whether the adaptation

ability and characteristics of the product change.


Standard:

Test methods for environmental test equipment for electrical and electronic products

-- Temperature test equipment

Test methods for environmental test equipment for electrical and electronic products

-- Humidity and heat test equipment

JJF1101-2003 environmental test equipment temperature, humidity calibration specification


Specifications:
Test Space Volume (m³) 8 12 17 28
Test Space Dimension (mm) 2000W*2000D*2056H 2000W*2000D*3040H 2250W×2500D×3032H 2250W*2500D*5000
External Dimension (mm) 2240W*2240D*3800H 2240W*2240D*4780H 2490W*2740D*4900H 2490W*2740D*6860
Floor Load (N/m³)

30000

ETZ Series: -60,-40 / +80,+100,+150, +180 optional
Temp. Range (ºC) (NoLoad) ECZ Series: 0 / +80,+100 optional
Humid. Range (%RH) ETCZ Series: -60,-40 / +80,+100,+150 optional

Dewpoint Temp. Range (ºC)

15~95 (ETZ,ETCZ Series)

+4~+59 / +4~+95

Heating /Cooling Rate (IEC60068-3-5)
Level 1 (K/min) 4.5 3.7 2.7 1.7
Level 2 (K/min) 5.5 4.5 3.2 2.0
Temp. Constancy (K) ±0.1~±0.5 (IEC60068-3-5)
Temp.Homogeneity (K) ±0.5~±3.0 (IEC60068-3-5)
Humid. Constancy Entry (%RH) ±1.0~±5.0 (IEC60068-3-5) (ECZ, ETCZ Series)
Door Dimension Power(mm) 900W×1900H(Single door) , 2000W*2000H (Double door)
Power AC 380V±10%, 50HZ , 3/N/PE

Options Accessories

Standard Version

Independent sensors for specimen protection (NE60519-2.1993)

1 Entry port Φ100mm

1 Entry port Φ50mm

1 Silicon stopper for entry port

Drier filter for compressingair

Automatic water supply

Ultrasonic Humidifier

1 Water tank with 20L

Nitrogen gas auxiliary device

1 Water filter

Water-Cooled unit

Spare parts package

E-management and cyber-software

Video monitor system

APP for mobility management


High-Accuracy Walk-in Temperature and Humidity Test Chamber Compliant With IEC 60068-2-2 and Stainless Steel 304 Construction

High-Accuracy Walk-in Temperature and Humidity Test Chamber Compliant With IEC 60068-2-2 and Stainless Steel 304 Construction

High-Accuracy Walk-in Temperature and Humidity Test Chamber Compliant With IEC 60068-2-2 and Stainless Steel 304 Construction

High-Accuracy Walk-in Temperature and Humidity Test Chamber Compliant With IEC 60068-2-2 and Stainless Steel 304 Construction

High-Accuracy Walk-in Temperature and Humidity Test Chamber Compliant With IEC 60068-2-2 and Stainless Steel 304 Construction
High-Accuracy Walk-in Temperature and Humidity Test Chamber Compliant With IEC 60068-2-2 and Stainless Steel 304 Construction
Our service:
During the whole business process, we offer a Consultative Selling services.
1)Customer inquiry process:
Discussing testing requirements and technical details, suggested suitable products to customer to confirm.
Then quote the most suitable price according to customer requirements.

2)Specifications customize process:
Drawing related drawings to confirm with customer for customized requirements. Offer reference photos to show the appearance of the product. Then, confirm the final solution and confirm the final price with the customer.

3)Production and delivery process:
We will produce the machines according to confirmed PO requirements. Offering photos to show the production process.
After finishing production, offer photos to the customer to confirm again with the machine. Then do your own factory calibration or third-party calibration(as per customer requirements). Check and test all the details and then arrange packing.
Delivering the products is confirmed shipping time and informed the customer.

4)Installation and after-sale service:
Defines installing those products in the field and providing after-sales support.

FAQ:
1. Are you a Manufacturer? Do you offer after-sales service? How can I ask for that? And how about the warranty?
Yes, we are the one of professional manufacturers of Environmental Chambers, Leather shoe testing equipment, and Plastic Rubber testing Equipment... in China. Every machine purchased from our factory has 12 month warranty after shipment. Generally, we offer 12 months for FREE maintenance. while considering sea transportation, we can extend 2 months for our customers.
Moreover, If your machine doesn't work, you can send us an e-mail or call us we will try our best to find the problem through our conversation or by video chat if necessary. Once we have confirmed the problem, the solution will be offered within 24 to 48 hours.
2. What about the delivery term?
For our standard machine which means normal machines, If we have stock in the warehouse, is 3-7 working days;
If there is no stock, normally, the delivery time is 15-20 working days after payment is received;
If you are in urgent need, we will make a special arrangement for you.
3. Do you accept customization services? Can I have my logo on the machine?
Yes, of course. We can not only offer standard machines but also customized machines according to your requirements. And we can also put your logo on the machine which means we offer OEM and ODM service.
4. How can I install and use the machine?
Once you have ordered the testing machines from us, we will send you the operation manual or video in English version through Email.
Most of our machine is shipped with a whole part, which means it is already installed, you just need to connect the power cable and start to use it. And if it's necessary, we can also assist you to install your machine on-site.
