UP-6111 High-humidity Rapid Temperature Change Environmental Test Chamber with Steam Generator
UP-6111 High-humidity Rapid Temperature Change Environmental Test Chamber with Steam Generator
UP-6111 High-humidity Rapid Temperature Change Environmental Test Chamber with Steam Generator
UP-6111 High-humidity Rapid Temperature Change Environmental Test Chamber with Steam Generator
Specifications
Model Number :
UP-6111
Delivery Time :
5-15 work days
Emperature Range :
-70ºC~+180ºC
Humidity Fluctuation :
±2.5%Rh
Place of Origin :
CHINA
Brand Name :
YOUBI
Payment Terms :
T/T,D/P,Western Union,Paypal,Money Gram
Packaging Details :
Professional Export Wooden Box Packaging
Supply Ability :
30 Unit/month
Heating Rate :
5ºC/Min
Certification :
CE,ISO
MOQ :
1 Unit
Price :
Negotiable
Custom Service :
OEM,ODM
Product name :
Rapid temperature change test chamber
Warranty :
1 Year
Size Service :
Support Customer Customization
Humidity Range :
10%~98%Rh
Third-Party Calibration Service :
Support Customer Customization
Cooling Rate :
5ºC/Min
Model NO. :
UP-6111
Temperature Fluctuation :
±1ºC
Description
UP-6111 High-humidity Temperature And Humidity Test Chamber With Steam Generator
Precision environmental testing chamber designed for industrial applications requiring controlled temperature and humidity conditions with steam generation capabilities.
UP-6111 High-humidity Rapid Temperature Change Environmental Test Chamber with Steam Generator
Key Features
  • Strategic cable ports on left side for easy electrical connections and specimen measurements
  • Robust hinges prevent door auto-closing, ensuring safe access during testing operations
  • Compliant with major environmental testing standards including IEC, JEDEC, and SAE
  • Quiet operation at only 80 dBA for accurate data collection and analysis
  • Precise temperature control from -70°C to +180°C
  • Wide humidity range of 10% to 98% RH
  • OEM and ODM customization support available
  • Large 100-liter working capacity
  • 1-year warranty for reliability and durability
Applications
  • Simulation of test environments with varying temperature and humidity conditions
  • Cyclic testing including holding tests, cooling-off tests, heating-up tests, and drying tests
Design Features
  • Cable ports on left side for easy specimen wiring
  • Hinges prevent door auto-closing during operation
  • Compliant with major environmental test standards
  • CE certified for safety compliance
Programmable Controller
  • High-precision programmable touch screen controller
  • Step types include ramp, soak, jump, auto-start, and end functions
Technical Specifications
Parameter Specification
Internal Dimension (W×D×H) 1000×800×1000mm
External Dimension (W×D×H) 1580×1700×2260mm
Working Capacity 800 liter
Internal Chamber Material SUS#304 stainless steel, mirror finished
External Chamber Material Stainless steel with paint spray
Temperature Range -70°C to +180°C
Temperature Fluctuation ±1°C
Heating Rate 5°C/min
Cooling Rate 5°C/min
Sample Tray SUS#304 stainless steel, 3pcs
Testing Hole Diameter 50mm, for cable routing
Power Three-phase, 380V/50Hz
Safety Protection Leakage, over-temperature, compressor over-voltage and overload, heater short circuit
Insulation Material Compound material without sweating, special for low pressure
Heating Method Electrical
Compressor Imported new generation with low noise
UP-6111 High-humidity Rapid Temperature Change Environmental Test Chamber with Steam Generator UP-6111 High-humidity Rapid Temperature Change Environmental Test Chamber with Steam Generator UP-6111 High-humidity Rapid Temperature Change Environmental Test Chamber with Steam Generator UP-6111 High-humidity Rapid Temperature Change Environmental Test Chamber with Steam Generator
Our Service Process
Customer Inquiry: Technical consultation and product recommendation based on testing requirements
Customization: Detailed drawings and specifications confirmation for customized solutions
Production & Delivery: Production updates, quality checks, calibration, and timely shipping
Installation & Support: Field installation and comprehensive after-sales service
Frequently Asked Questions
  • Are you a manufacturer? What is your warranty policy?
    Yes, we are professional manufacturers of environmental chambers. We offer 12-month warranty with free maintenance, extendable to 14 months considering sea transportation. Technical support available via email or video chat.
  • What is your delivery time?
    Standard machines: 3-7 working days if in stock, 15-20 working days if no stock. Urgent orders receive special arrangements.
  • Do you accept customization and OEM services?
    Yes, we offer both standard and customized machines according to your requirements, including OEM and ODM services with your logo.
  • How do I install and use the machine?
    Most machines are shipped fully assembled. We provide English operation manuals and videos. Simply connect power cable to start. On-site installation assistance available when necessary.
