UP-6195 High-Efficiency Finned Evaporator Temperature Humidity Test Chamber with -70~180ºC Range and 20%~98% Humidity Control
UP-6195 High-Efficiency Finned Evaporator Temperature Humidity Test Chamber with -70~180ºC Range and 20%~98% Humidity Control
UP-6195 High-Efficiency Finned Evaporator Temperature Humidity Test Chamber with -70~180ºC Range and 20%~98% Humidity Control
UP-6195 High-Efficiency Finned Evaporator Temperature Humidity Test Chamber with -70~180ºC Range and 20%~98% Humidity Control
UP-6195 High-Efficiency Finned Evaporator Temperature Humidity Test Chamber with -70~180ºC Range and 20%~98% Humidity Control
UP-6195 High-Efficiency Finned Evaporator Temperature Humidity Test Chamber with -70~180ºC Range and 20%~98% Humidity Control
Specifications
Certification :
CE,ISO
MOQ :
1 Unit
Price :
$599~$8999
Place of Origin :
CHINA
Brand Name :
YOUBI
Payment Terms :
T/T; D/P; Wester Union; Paypal; Money Gram
Packaging Details :
Professional Export Wooden Box Packaging
Supply Ability :
30 Unit/month
Model Number :
UP-6195
Delivery Time :
5~15 work days
Model NO. :
UP-6195
Warranty :
1 Year
Additional Service :
Support Customer Customization
Custom Service :
OEM,ODM
Temperature Range :
-70~180ºC
Humidity Range :
20%~98%
Color Service :
Support Customer Customization
Size Service :
Support Customer Customization
Third-Party Calibration Service :
Support Customer Customization
Specification :
Refer to the actual size specifications
Description
UP-6195 High-Efficiency Finned Evaporator New Energy Sources Temperature Humidity Test Chamber
The UP-6195 High-efficiency Finned Evaporator New Energy Sources Temperature Humidity Test Chamber is designed for rigorous environmental testing with advanced features and reliable performance.
Key Features
  • Graceful circular body design with mist strip surface treatment
  • Rectangular double-paned viewing window with interior lighting
  • Double-layer insulated airtight doors for effective temperature insulation
  • Externally connectable water supply system with automatic recycling
  • French Tecumseh compressor using environmentally friendly R23 or R404A refrigerant
  • LCD display showing measured values, set values, and time
  • Multi-segment program editing with quick or ramp rate temperature/humidity control
  • Mobility casters with strong positioning screws
Design Standards
GB2423/T5170/10586/10592, IEC60068, GJB150, JIS C60068, ASTM D4714, CNS3625/12565/12566
Applications
This equipment simulates various environmental conditions for testing material performance including heat resistance, dry resistance, humidity resistance, and cold resistance to define material characteristics.
Technical Specifications
Model UP-6195
System Temperature & Humidity Balance Control (BTHC) System
Test Area Volume 1000 liters
Test Area Load Capacity 100 kg
Internal Dimensions W×H×D (mm) 1000×1000
External Dimensions W×H×D (mm) 1200×2050×1780
Weight 860KG
Power Supply 1φ 220V AC & 50/60 Hz, 24A or 3φ 380V AC & 50/60 Hz, 10A
Temperature Range -70℃ ~ +100℃ (+150℃/+180℃)
Humidity Range 10~98% RH
Temperature and Humidity Fluctuation ±0.3 ℃ / ±2.5% RH
Temperature Uniformity 1.5 ℃
Temperature Change Rate Heating Rate: 3.0 ℃/min
Cooling Rate: 2.0 ℃/min
Extreme Temperature Ramp Time Heating Time: from +20 to +100 ℃: 30 min
Cooling Time: from +20 to -20 ℃: 20 min
Permissible Heat Load At test area temperature of +20 ℃: 300 W
Refrigeration Unit System Mechanical single-stage compression cooling
Compressor Scroll / Piston compressor
Refrigerant R404A [R449A available on request]
Power 4.8kw
Noise Level 6dB
Product Images
UP-6195 High-Efficiency Finned Evaporator Temperature Humidity Test Chamber with -70~180ºC Range and 20%~98% Humidity Control UP-6195 High-Efficiency Finned Evaporator Temperature Humidity Test Chamber with -70~180ºC Range and 20%~98% Humidity Control UP-6195 High-Efficiency Finned Evaporator Temperature Humidity Test Chamber with -70~180ºC Range and 20%~98% Humidity Control UP-6195 High-Efficiency Finned Evaporator Temperature Humidity Test Chamber with -70~180ºC Range and 20%~98% Humidity Control
Our Service Process
  • Customer Inquiry: Technical consultation, product recommendations, and quotation based on requirements
  • Customization: Detailed drawings, reference photos, and final solution confirmation
  • Production & Delivery: Production updates, final confirmation photos, calibration, and timely shipping
  • Installation & Support: Field installation and comprehensive after-sales service
Frequently Asked Questions
Are you a Manufacturer? Do you offer after-sales service? How can I ask for that? And how about the warranty?
Yes, we are professional manufacturers of Environmental Chambers, Leather shoe testing equipment, and Plastic Rubber testing Equipment. Every machine includes a 12-month warranty after shipment, with free maintenance during this period. We extend an additional 2 months consideration for sea transportation. For technical support, contact us via email or phone - we diagnose issues through conversation or video chat and provide solutions within 24-48 hours.
What about the delivery term?
Standard machines in stock: 3-7 working days. Custom orders: 15-20 working days after payment. Urgent requirements receive special arrangement priority.
Do you accept customization services? Can I have my logo on the machine?
Yes, we offer both standard and customized machines according to your specifications. We provide OEM and ODM services including logo placement.
How can I install and use the machine?
We provide English operation manuals and videos via email. Most machines ship fully assembled - simply connect power and begin operation. On-site installation assistance is available when necessary.
