5025 SMD Chip Ferrite Bead 100-1100Ω MLCC High Performance RoHS Compliant
5025 SMD Chip Ferrite Bead 100-1100Ω MLCC High Performance RoHS Compliant
Specifications
Size :
5025
Packaging :
Tape & Reel
Mounting Type :
Surface Mount
Certification :
RoHS Compliant
Impedance Range :
100-1100Ω
Brand Name :
JYRF
Model Number :
JY-SPB5025D Series
Product Type :
Multilayer Chip Ferrite Bead
Place of Origin :
China
Operating Temperature :
-40℃ to +85℃
Description

JY-SPB5025D Series Chip Ferrite Bead 100-1100Ω 5025 SMD High Performance RoHS Compliant

Part Numbering System

Position Code Description
1 JYSPB Product code
2 0603 Product size
3 D Series type
4 900 Impedance code
5 P Tolerance: P±25% / N±30%
6 T Packaging: T tape & reel / B bulk
7 HF Environment: LF / HF / FP

Configuration and Dimensions

A 4.8 B 5.0 C 2.7 (unit: mm)

General Specifications

  • Operating temperature range: -40℃ to +85℃
  • Storage temperature: -10℃ to +40℃, R.H. 65% Max
  • Moisture sensitivity level: MSL 2
  • Rated DC current: temperature rise (ΔT) approx. 40℃ at Irms
  • RoHS compliant, lead-free and halogen-free available

Electrical Characteristics

Part Number Impedance Z (Ω) Test Freq. (MHz) DCR Max (Ω) Irms Max (A) Rated Voltage (V) Insulation Res. Min (MΩ)
JYSPB5025D101PTHF 100 100 12.60 6.50 50 10
JYSPB5025D251PTHF 250 100 19.60 5.00 50 10
JYSPB5025D501PTHF 500 100 22.60 4.00 50 10
JYSPB5025D102PTHF 1000 100 33.60 2.00 50 10
JYSPB5025D142PTHF 1100 100 56.00 1.50 50 10

Note: Measured at 25℃. Rated DC current based on temperature rise of approx. 40℃ at Irms.

Soldering Conditions

  • Reflow soldering (lead-free): preheat to 150℃; peak temperature 260℃ (max); reflow times ≤2; solder paste thickness 0.08mm optimal / 0.1mm max
  • Hand soldering: 20W iron with 1.0mm tip diameter; soldering time within 3 seconds

Packaging

Tape and reel packaging. Peel force: 20g-80g, peel speed 300mm/min±10%. Tape & Reel, 2500 pcs/reel.
