90-2200Ω Chip Ferrite Bead 1206 SMD High Performance RoHS Compliant
90-2200Ω Chip Ferrite Bead 1206 SMD High Performance RoHS Compliant
Specifications
Product Type :
Multilayer Chip Ferrite Bead
Certification :
RoHS Compliant
Brand Name :
JYRF
Operating Temperature :
-40℃ to +105℃
Size :
1206
Packaging :
Tape & Reel
Mounting Type :
Surface Mount
Impedance Range :
90-2200Ω
Model Number :
JY-SPB1206D Series
Place of Origin :
China
Description

JY-SPB1206D Series Chip Ferrite Bead 90-2200Ω 1206 SMD High Performance RoHS Compliant

Part Numbering System

Position Code Description
1 JYSPB Product code
2 0603 Product size
3 D Series type
4 900 Impedance code
5 P Tolerance: P±25% / N±30%
6 T Packaging: T tape & reel / B bulk
7 HF Environment: LF / HF / FP

Configuration and Dimensions

A 3.2 B 1.6 C 1.9 (unit: mm)

General Specifications

  • Operating temperature range: -40℃ to +105℃
  • Storage temperature: -10℃ to +40℃, R.H. 65% Max
  • Moisture sensitivity level: MSL 2
  • Rated DC current: temperature rise (ΔT) approx. 40℃ at Irms
  • RoHS compliant, lead-free and halogen-free available

Electrical Characteristics

Part Number Impedance Z (Ω) Test Freq. (MHz) DCR Max (Ω) Irms Max (A) Rated Voltage (V) Insulation Res. Min (MΩ)
JYSPB1206D900PTHF 90 100 0.30 0.37 50 10
JYSPB1206D121PTHF 120 100 0.30 0.35 50 10
JYSPB1206D161PTHF 160 100 0.40 0.34 50 10
JYSPB1206D221PTHF 220 100 0.45 0.30 50 10
JYSPB1206D261PTHF 260 100 0.50 0.31 50 10
JYSPB1206D361PTHF 360 100 0.60 0.30 50 10
JYSPB1206D601PTHF 600 100 0.80 0.26 50 10
JYSPB1206D801PTHF 800 100 0.90 0.24 50 10
JYSPB1206D102PTHF 1000 100 1.00 0.23 50 10
JYSPB1206D142PTHF 1400 100 1.00 0.22 50 10
JYSPB1206D202PTHF 2000 100 1.20 0.20 50 10
JYSPB1206D222PTHF 2200 100 1.20 0.20 50 10

Note: Measured at 25℃. Rated DC current based on temperature rise of approx. 40℃ at Irms.

Soldering Conditions

  • Reflow soldering (lead-free): preheat to 150℃; peak temperature 260℃ (max); reflow times ≤2; solder paste thickness 0.08mm optimal / 0.1mm max
  • Hand soldering: 20W iron with 1.0mm tip diameter; soldering time within 3 seconds

Packaging

Tape and reel packaging. Peel force: 20g-80g, peel speed 300mm/min±10%. Tape & Reel, 2000 pcs/reel.
