Oem DC Chip Ferrite Bead 80-2800Ω 1812 SMD Lead Free
Oem DC Chip Ferrite Bead 80-2800Ω 1812 SMD Lead Free
Specifications
Model Number :
JY-SPB1812D Series
Product Type :
Multilayer Chip Ferrite Bead
Brand Name :
JYRF
Size :
1812
Packaging :
Tape & Reel
Certification :
RoHS Compliant
Mounting Type :
Surface Mount
Impedance Range :
80-2800Ω
Operating Temperature :
-40℃ to +85℃
Place of Origin :
China
Description

JY-SPB1812D Series Chip Ferrite Bead 80-2800Ω 1812 SMD High Performance RoHS Compliant

Part Numbering System

Position Code Description
1 JYSPB Product code
2 0603 Product size
3 D Series type
4 900 Impedance code
5 P Tolerance: P±25% / N±30%
6 T Packaging: T tape & reel / B bulk
7 HF Environment: LF / HF / FP

Configuration and Dimensions

A 4.5 B 3.2 C 2.8 (unit: mm)

General Specifications

  • Operating temperature range: -40℃ to +85℃
  • Storage temperature: -10℃ to +40℃, R.H. 65% Max
  • Moisture sensitivity level: MSL 2
  • Rated DC current: temperature rise (ΔT) approx. 40℃ at Irms
  • RoHS compliant, lead-free and halogen-free available

Electrical Characteristics

Part Number Impedance Z (Ω) Test Freq. (MHz) DCR Max (Ω) Irms Max (A) Rated Voltage (V) Insulation Res. Min (MΩ)
JYSPB1812D800PTHF 80 100 0.05 3.0 50 10
JYSPB1812D900PTHF 90 100 0.09 3.0 50 10
JYSPB1812D121PTHF 120 100 0.10 3.0 50 10
JYSPB1812D201PTHF 200 100 0.10 1.5 50 10
JYSPB1812D221PTHF 220 100 0.10 1.3 50 10
JYSPB1812D331PTHF 330 100 0.11 1.1 50 10
JYSPB1812D601PTHF 600 100 0.12 1.0 50 10
JYSPB1812D701PTHF 700 100 0.12 1.5 50 10
JYSPB1812D801PTHF 800 100 0.16 0.9 50 10
JYSPB1812D901PTHF 900 100 0.17 1.0 50 10
JYSPB1812D102PTHF 1000 100 0.18 0.8 50 10
JYSPB1812D142PTHF 1400 100 0.20 0.7 50 10
JYSPB1812D282PTHF 2800 100 0.35 0.8 50 10

Note: Measured at 25℃. Rated DC current based on temperature rise of approx. 40℃ at Irms.

Soldering Conditions

  • Reflow soldering (lead-free): preheat to 150℃; peak temperature 260℃ (max); reflow times ≤2; solder paste thickness 0.08mm optimal / 0.1mm max
  • Hand soldering: 20W iron with 1.0mm tip diameter; soldering time within 3 seconds

Packaging

Tape and reel packaging. Peel force: 20g-80g, peel speed 300mm/min±10%. Tape & Reel, 500 pcs/reel.
