MDC1-15SW1 MDC Series Micro Rectangular Electrical Connectors 15 Contact
MDC1-15SW1 MDC Series Micro Rectangular Electrical Connectors 15 Contact
MDC1-15SW1 MDC Series Micro Rectangular Electrical Connectors 15 Contact
MDC1-15SW1 MDC Series Micro Rectangular Electrical Connectors 15 Contact
MDC1-15SW1 MDC Series Micro Rectangular Electrical Connectors 15 Contact
MDC1-15SW1 MDC Series Micro Rectangular Electrical Connectors 15 Contact
Specifications
Low pressure :
4.4 KPa, 150 V
Environmental temperature :
-55°C to +125°C
Model Number :
MDC1-15SW1
Price :
10$-500$
Impact :
490 m/s²
cInsulation resistance :
≥5000 MΩ
Contact resistance :
≤12 mΩ
Payment Terms :
L/C,T/T,Western Union
MOQ :
10pcs
Mechanical lifespan :
500 insertion and removal cycles
Relative humidity :
+40°C, 98%
Supply Ability :
10000pcs per month
Brand Name :
Jovelix
Place of Origin :
China
Delivery Time :
2-9weeks
Vibration :
10 Hz to 2000 Hz, 196 m/s 2
Rated current (maximum) :
2A Max
Certification :
AS9001
Pressure rating :
500V
Packaging Details :
standard export package
Description
MDC1 Series Micro-Rectangular Electrical Connector

The MDC1 Series Micro-Rectangular Electrical Connector is a compact, lightweight, and high-density interconnect solution designed for reliable electrical signal transmission in miniaturized electronic systems. With a 1 mm contact pitch and 0.866 mm row spacing, this series provides stable connection performance while saving installation space.

The product range includes 5, 9, 15, 21, 25, 31, 37, 51, 66, 74, and 100-pin configurations, offering flexible options for different circuit density requirements. It supports conductor crimping cross-sections from 0.035 mm² to 0.1 mm², making it suitable for compact wiring layouts and high-density equipment integration.

With vibration resistance from 10 Hz to 2000 Hz at 196 m/s², impact resistance of 490 m/s², an operating temperature range of -55°C to +125°C, and a mechanical life of 500 mating cycles, the MDC1 Series provides reliable performance for demanding miniature interconnection applications.

Composition of MDC1 series models
Order number Classification Feature Category Content Label Code
1 Subject Code Micro-rectangular connector MDC1
2 Number of contact points Number of contact points Represented in Arabic numerals
3 Types of Contact Parts Pin contact piece P
Plug contact piece S
4 Product type Closed type M
5 End termination type Crimping(with wire) Not labeled
Weld S
Straight PCB Solder Mount N
Right-angle PCB Solder Mount W
Vertical Label Type N1
6 Installation Attachment Free-end locking accessory L
Fixed-end installation accessory P

MDC1-15SW1 MDC Series Micro Rectangular Electrical Connectors 15 ContactMDC1-15SW1 MDC Series Micro Rectangular Electrical Connectors 15 Contact
