M6 Terminal 12V 150AH Solar Gel Battery with 15 Years Life for Wind Power Systems
M6 Terminal 12V 150AH Solar Gel Battery with 15 Years Life for Wind Power Systems
Specifications
Applications :
Wind Power System, Electric Power Vehicles, Wheel Chairs, Power tools
Battery Case :
ABS
Rated Capacity :
150AH
Brand Name :
FBATTERY
Battery Designed Life :
15 Years
Nominal Voltage :
12 Volt
Type :
12v 150ah Solar Gel Battery
Internal Resistance :
~0.006Ohm
Terminal Type :
M6 Terminal
Dimension :
L484mm x W170mm x H240mm
Approx Weight :
46 Kg
Model Number :
6GFM-150G
Certification :
CE UL ISO9001 ISO14001 OHASA18001
Place of Origin :
WUHAN
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T,D/P,L/C
Supply Ability :
10000PCS/Week
Delivery Time :
30Days
Packaging Details :
Carton and Wooden Pallet
Description
M6 Terminal 12V 150Ah Solar Gel Battery in Wind Power System
Applications
  • Solar/Wind Power Systems
  • Uninterruptible Power Supplies (UPS)
  • Electric Power Systems (EPS)
  • Emergency Backup Power Supplies
  • Communication Power Supplies
  • DC Power Supplies
  • Auto Control Systems
Product Structure and Working Principle
  • Positive plate: Thick high Sn low Ca grid minimizes corrosion and prolongs life
  • Negative plate: Balanced Pb-Ca grid for improved recombination efficiency
  • Separator: Advanced AGM separator for ultra low float current
  • Electrolyte: Dilute high purity sulphuric acid with nano gel
  • Battery container and cover: ABS material
Specifications
Type Gel Deep Cycle Battery
Nominal Voltage 12V
Rated Capacity 65Ah (10 Hr, 10.8V, 25℃)
Dimensions (L*W*H) 350mm * 166mm * 179mm
Cycle Life ≥ 3 years
Weight 21kg
Operating Temperature -40℃ to 60℃
Optimum Temperature 20℃ to 25℃
Self-discharge Rate < 0.1% per day (20℃)
Container Material ABS
Screw Hole Size M6
Constant Current Discharge Ratings (Amperes at 25°C)
F.V/Time 5min 10min 15min 30min 1h 2h 3h 4h 5h 8h 10h 20h
1.6V 195 144 119 73.2 43.9 25.5 18.4 14.7 12.2 8.35 6.89 3.71
1.67V 174 133 112 69.9 42.8 25.1 18.2 14.5 12.1 8.24 6.81 3.63
1.7V 155 120 106 67.3 41.8 24.7 18.0 14.3 12.0 8.14 6.72 3.54
1.75V 135 112 98.2 65.0 40.9 24.3 17.7 14.2 11.8 8.03 6.63 3.48
1.80V 119 102 91.6 62.1 39.6 23.8 17.4 13.9 11.5 7.84 6.50 3.41
1.85V 102 91.6 83.5 58.6 37.9 22.9 16.8 13.5 11.3 7.67 6.33 3.33
Constant Power Discharge Ratings (Watts at 25°C)
F.V/Time 5min 10min 15min 30min 1h 2h 3h 4h 5h 8h 10h 20h
1.6V 343 259 217 135 81.9 47.9 34.8 27.8 23.3 16.1 13.3 7.20
1.65V 310 241 206 130 80.2 47.4 34.6 27.7 23.2 16.0 13.2 7.09
1.70V 280 221 196 126 78.9 47.1 34.4 27.6 23.1 15.9 13.1 6.99
1.75V 247 208 184 123 77.9 46.7 34.2 27.5 23.0 15.8 13.0 6.89
1.80V 221 191 173 118 76.0 46.1 33.8 27.1 22.6 15.5 12.9 6.81
1.85V 193 174 159 113 73.5 44.7 33.0 26.5 22.3 15.3 12.7 6.70
Application Fields

Solar Power Systems, Wind Energy Storage Systems, UPS systems, switchgear, CATV and telecommunication systems applications, electric wheelchairs field, medical equipment field, washing machines field and more.

Advantages
  • Long Life: VRLA gel type battery uses high-tin alloy positive grids and thick plates to reduce active material utilization. 40% DOD cycle life can reach over 3000 times as per IEC 60896-22-2004.
  • Super Overdischarge Tolerance: After 5 over-discharges causing short circuits, battery capacity restoration reaches over 95%.
  • High Cycling Ability: Special gel electrolyte additives and curing process delay active material softening, improving deep cycle endurance and anti-passivation capability.
  • Excellent High-current Performance: Tight assembly design reduces plate distance, improving high current discharge performance.
  • Safety: Corrosion-resistant rubber O-ring and special adhesive seal terminals, ensuring no acid leakage and reliable operation.
  • Maintenance Free: Low liquid design recombines generated gases into water; no need to add water or acid.
  • Various Installation Types: Special AGM separator absorbs electrolyte, allowing both vertical and horizontal mounting positions.
